WAGO 250-108 PCB terminal block
Part Number # 250-108
SKU # 2273646
$46.89 / 40Each
Wago 250-108 Key Features
Brand: Wago
Part Number # 250-108
SKU #2273646
Amperage Rating: 8 A
Dimensions: 0.657 in H x 1.161 in W x 0.472 in D
Number of Poles: 8
Spacing: 0.138 in
Type: Push Button
Voltage Rating: 320 V
Wire Size: 24 to 16 AWG
Actuation type: Push-button
Approvals per: CSA, UL 1059
Color: Gray
Connection technology: Push-in CAGE CLAMP®
Connection type: Push-In
Contact material: Electrolytic copper (ECu)
Country of origin: CH
Depth: 12 mm / 0.472 inch
Height: 16.7 mm / 0.657 inch
Insulation material: Polyamide (PA66)
Material: Polyamide
Number of connection types: 1
Rated current: 0.333333333333333
Solid conductor: 0.2 … 1.5 mm² / 24 … 16 AWG
Total number of connection points: 8
Weight: 3.821 g
Width: 29.5 mm / 1.161 inch
Manufacturer Name: WAGO Corporation
UNSPSC: 39121410
UPC: 04044918647465
$46.89 / 40Each
- WAGO, 250-108, PCB Terminal Block, Push Button, 320 V, 8 A, 8 Pole, 24 to 16 AWG Wire, 0.33 to 0.37 in Wire Strip Length, 0.138 in Spacing, Push-In Connection, Polyamide, Gray, 0.657 in H x 1.161 in W x 0.472 in D Dimensions
250-108 Item Features
- Compact terminal strips with push-buttons
- Push-in terminations of solid and ferruled conductors
- Termination/removal of fine-stranded conductors via push-buttons
- 45 deg conductor entry angle provides easy, space-saving wiring
- Custom color combinations
- Terminal strips also available with spacers upon request
250-108 Standards
CSA|IEC/EN 60664-1|RoHS CompliantSKU #2273646Part Number #250-108UNSPSC39121410UPC04044918647465
