WAGO 261-304 2-conductor terminal block
Part Number # 261-304
SKU # 2245820
$43.00 / 50Each
Wago 261-304 Key Features
Brand: Wago
Part Number # 261-304
SKU #2245820
Amperage Rating: 24 A
Dimensions: 0.713 in H x 0.236 in W x 1.106 in D
Number of Poles: 1
Type: Operating Tool
Voltage Rating: 500 V
Wire Size: 28 to 14 AWG
Actuation type: Operating tool
Color: Blue
Connection technology: CAGE CLAMP®
Connection type: Clamp
Country of origin: CH
Depth: 28 mm / 1.102 inch
Material: Polyamide
Mounting type: Flange, Mounting flange
Rated current: 24 A
Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Total number of connection points: 2
Weight: 2.344 g
Width: 6 mm / 0.236 inch
Wiring type: Side-entry wiring
Manufacturer Name: WAGO Corporation
UNSPSC: 39121407
UPC: 04044918611251
$43.00 / 50Each
WAGO 261-304 2-conductor terminal block
Brand: Wago
Part Number: 261-304
Additional Description: WAGO-261-304 2-CONDUCTOR TERMINAL BLOCK; SUITABLE FOR EX I APPLICATIONS; WITHOUT PUSH-BUTTONS; WITH FIXING FLANGE; FOR SCREW OR SIMILAR MOUNTING TYPES; FIXING HOLE 3.2 MM ; 2.5 MM ; CAGE CLAMP ; 2,50 MM ; BLUE 51137591
Catalog Description: 2-conductor terminal block; without push-buttons; suitable for Ex i applications; with fixing flange; 1-pole; for screw or similar mounting types; Fixing hole 3.2 mm Ø; 2.5 mm²; CAGE CLAMP®; 2,50 mm²; blue
261-304 Application
Suitable for Ex i applications261-304 Standards
CSA 22.2 No 158|RoHS CompliantSKU #2245820Part Number #261-304UNSPSC39121407UPC04044918611251
