Part Number # 2857-401
SKU # 2302952
Image Disclaimers Message
Brand: Wago
2857-401
WAGO 2857-401 JUMPFLEX signal conditioner
Part Number # 2857-401
SKU # 2302952
$847.32 / Each
Wago 2857-401 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2857-401 |
| SKU #: | 2302952 |
| Dimensions: | 4.331 in H x 0.492 in W x 4.213 in D |
| Input Voltage: | 250 V |
| Specifications: | 9 millimeter Length |
| Connection technology: | Push-in CAGE CLAMP® |
| Connection type: | Push-In |
| Country of origin: | DE |
| Depth: | 110 mm / 4.331 inch |
| Input current: | 120 mA |
| Input signal (current): | ±1 mA; 0 … 1 mA; ±10 mA; 0 … 10 mA; 2 … 10 mA; ±20 mA; 0 … 20 mA; 4 … 20 mA; ±100 mA; 0 … 100 mA |
| Input signal (voltage): | ±1 V; 0 … 1 V; ±5 V; 0 … 5 V; 1 … 5 V; ±10 V; 0 … 10 V; 2 … 10 V; ±30 V; 0 … 30 V; ±100 V; 0 … 100 V; ±200 V; 0 … 220 V |
| Input signal type: | Voltage || Current |
| Mounting type: | 35 mm DIN Rail, DIN-35 rail |
| Output signal (current): | ±10 mA; 0 … 10 mA; 2 … 10 mA; ±20 mA; 0 … 20 mA; 4 … 20 mA |
| Output signal (voltage): | ± 5 V; 0 … 5 V; 1 … 5 V; ± 10 V; 0 … 10 V |
| Output signal type: | Voltage || Current |
| Power consumption at nominal supply voltage: | ≤ 70 mA (+ IDO) |
| Power supply type: | 24 VDC |
| Solid conductor: | 0.2 … 2.5 mm² / 24 … 12 AWG |
| Standards/Specifications: | EN 60664-1; EN 61373 |
| Supply voltage range: | ±30 % |
| WAGO Connector: | picoMAX® 5.0 |
| Weight: | 85.859 g |
| Width: | 12.5 mm / 0.492 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 43232306 |
| UPC: | 04050821676966 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$847.32 / Each
Quantity:
WAGO 2857-401 JUMPFLEX signal conditioner
Brand: Wago
Part Number: 2857-401
Additional Description: WAGO-2857-401 ISO-AMP UIBIP UIBIP 28570401
Catalog Description: Isolation amplifier; Bipolar current and voltage input signal; Bipolar current and voltage output signal; Digital output; Supply voltage: 24 VDC; 12.5 mm module width
2857-401 Item Features
- Analog unipolar/bipolar signals at both input and output
- Digital signal output reacts to configured measurement range limits (configurable on/off switching delay and threshold value switch function with up to two threshold values)
- Digital HOLD input freezes the output signal
- Clipping capability for analog signal limitation to output end values
- Adjustable software/hardware filter
- Input/output response simulation via configuration display
2857-401 Standards
EN 60664-1|EN 61373|EN 50121-3-2|EN 50121-3-2|EN 60664-1|EN 61373|RoHS Compliant|CE|IP20SKU #2302952Part Number #2857-401UNSPSC43232306UPC04050821676966
