WAGO 289-458 Interface module

Name: WAGO 289-458 Interface module
Brand: Wago
Price: 116.09 USD
Availability: OutOfStock

Part Number # 289-458

SKU # 2257467

$116.09 / Each

Wago 289-458 Key Features

Brand: Wago

Part Number # 289-458

SKU #2257467

Amperage Rating: 1 A

Dimensions: 2.5 in H x 4.724 in W x 0.748 in D

Number of Poles: 37

Temperature Rating (Degrees F): -20 to 50 deg C

Type: 2-Row

Voltage Rating: 30 VAC/50 VDC

Wire Size: 28 to 12 AWG

Country of origin: DE

Depth: 63.5 mm / 2.5 inch

For mating connector: With solder contact

Mounting type: 35 mm DIN Rail, DIN-35 rail

Operating voltage: ≤ AC 30 V; ≤ DC 50 V

Performance level: 2 / 200 mating cycles

Protection type: IP00*

Rated voltage: 50 V

Strain relief: UNC 4-40 stud bolt

Weight: 79.300 g

Width: 120 mm / 4.724 inch

Manufacturer Name: WAGO Corporation

UNSPSC: 32151603

UPC: 04045454480479

$116.09 / Each

Quantity

: WAGO 289-458 Interface module
Brand: Wago
Part Number: 289-458
Additional Description: WAGO-289-458 IM SUB-D F 51186810
Catalog Description: Interface module; with solder pin; Female connector; 37-pole; Mating connector with solder connection; Vertical mounting; PCB terminal blocks, double-row; with mounting feet; 2,50 mm²
289-458 Standards
EN 61010-2-201|RoHS Compliant|IP00
SKU #2257467
Part Number #289-458
UNSPSC32151603
UPC04045454480479
