WAGO 704-5013 Interface module for system wiring

Name: WAGO 704-5013 Interface module for system wiring
Brand: Wago
Price: 1013.06 USD
Availability: OutOfStock

Part Number # 704-5013

SKU # 2264400

$1013.06 / Each

Wago 704-5013 Key Features

Brand: Wago

Part Number # 704-5013

SKU #2264400

Dimensions: 4.134 in H x 2.953 in W x 2.559 in D

Number of Poles: 10

Temperature Rating (Degrees F): -25 to 40 deg C

Type: Triple-Deck

Voltage Rating: 24 VDC

Wire Size: 28 to 12 AWG

Country of origin: FR

Depth: 105 mm / 4.134 inch

Inputs/outputs: 8-channel relay output

Mechanical life: 10 x 106 switching operations

Mounting type: 35 mm DIN Rail, DIN-35 rail

Number of changeover/switchover contacts: 1

Operating voltage range: ±10 %

Rated voltage: 50 V

Status indicator: Green LED (channel) || Yellow LED (power supply)

Weight: 240.000 g

Width: 70 mm / 2.756 inch

Manufacturer Name: WAGO Corporation

UNSPSC: 43232306

UPC: 04045454980115

$1013.06 / Each

Quantity

: WAGO 704-5013 Interface module for system wiring
Brand: Wago
Part Number: 704-5013
Additional Description: WAGO-704-5013 INTERFACE MODULE FOR SYSTEM WIRING; PLUGGABLE CONNECTOR PER DIN 41651; MALE CONNECTOR; 10-POLE; 8-CHANNEL RELAY OUTPUT; 1 CHANGEOVER CONTACT; DOUBLE-DECK PCB TERMINAL BLOCKS; WITH MANUAL OPERATION; IN MOUNTING CARRIER; 2,50 MM 7045013 mnt 250mm PLUGGABLE CONNECTOR PER DIN 41651; MALE CONNECTOR; 10-POLE; 8-CHANNEL RELAY OUTPUT; 1 CHANGEOVER CONTACT; DOUBLE-DECK PCB TERMINAL BLOCKS; WITH MANUAL OPERATION; IN MOUNTING CARRIER; 2,50 MM 07045013
Catalog Description: Interface module for system wiring; Pluggable connector per DIN 41651; Male connector; 10-pole; 8-channel relay output; 1 changeover contact; Triple-deck PCB terminal blocks; with manual operation; in mounting carrier; 2,50 mm²
704-5013 Standards
DIN 41651|RoHS Compliant
SKU #2264400
Part Number #704-5013
UNSPSC43232306
UPC04045454980115
