Brand: Wago
WAGO 788-341 Relay module
Part Number # 788-341
SKU # 2244892
$27.89 / Each
Wago 788-341 Key Features
Brand: Wago
Part Number # 788-341
SKU #2244892
Amperage Rating: 16 A
Dimensions: 3.386 in H x 0.591 in W x 2.874 in D
Enclosure Type: IP20
Indicator: Red LED
Temperature Rating (Degrees F): -25 to 50 deg C
Voltage Rating: 24 VDC
Connection technology: Push-in CAGE CLAMP®
Connection type: Push-In
Country of origin: DE
Depth: 86 mm / 3.386 inch
Mechanical life: 5 x 106 switching operations
Mounting type: 35 mm DIN Rail, DIN-35 rail
Number of changeover/switchover contacts: 1
Protection type: IP20
Rated voltage: 250 V
Solid conductor: 0.34 … 2.5 mm² / 22 … 14 AWG
Standards/Specifications: EN 61010-2-201; EN 61810-1; EN 61373; UL 508 (max. 10 A)
Status indicator: Red LED || Mechanical
Switching capacity: AC-15: 3 A / AC 240 V; DC-13: 2 A / DC 24 V
Switching frequency with/without load (max.): 6 min-1 / 300 min-1
Weight: 55.200 g
Width: 15 mm / 0.591 inch
Manufacturer Name: WAGO Corporation
UNSPSC: 43232306
UPC: 04050821226758
$27.89 / Each
- WAGO, 788-341, Relay Module, 24 VDC, 16 A, Red LED Indicator, -25 to 50 deg C, Push-In Connection, IP20 Enclosure, 35 mm DIN Rail Mounting, 3.386 in H x 0.591 in W x 2.874 in D Dimensions
788-341 Standards
EN 61010-2-201|EN 61810-1|EN 61373|UL 508 (max. 10 A)|RoHS Compliant|IP20SKU #2244892Part Number #788-341UNSPSC43232306UPC04050821226758
