Weidmuller 8771430000 Socket Relay
Part Number # 8771430000
SKU # 2132391
$61.71 / Each
Weidmuller 8771430000 Key Features
Brand: Weidmuller
Part Number # 8771430000
SKU #2132391
Amperage Rating: 2 A
Coil Voltage: 24 VDC
Contact Form: 1CO
Dimensions: 83 mm L x 36 mm W x 14.4 mm H
Enclosure Type: IP67
Power Rating: 200 mW
Series: JACKPAC
Temperature Rating (Degrees F): -25 to 70 deg C
Terminal Type: M12 Plug/Socket
UNSPSC: 32151902
UPC: 04032248439638
$61.71 / Each
Weidmuller 8771430000 Socket Relay
Brand: Weidmuller
Part Number: 8771430000
Additional Description: WEID-8771430000 JPR 24VDC ISO 1CO M12 RELAY MODULE, 24 V DC ±20 %, FREE-WHEELING DIODE, 1 CO CONTACT (AGSNO) , 2 A, M12 PLUG/SOCKET, A-CODED
8771430000 Item Features
- Switching amplifiers are simply built into the actuator system controls
- Switching outputs can be amplified from 24 VDC/0.5 A to 24 VDC/2 A
- Galvanic isolation is optional, for insulating between the input and output circuits, which prevents conducted interference on the switching output
- Switched voltage feed at output via T-distributor
SKU #2132391Part Number #8771430000UNSPSC32151902UPC04032248439638
