Brand: Weidmuller
Weidmuller 2730440000 VPU Series Surge Protection, Electrical Ratings: 120 VAC, 50/60 Hz, 1 Poles, 200 kA Short Circuit
Part Number # 2730440000
SKU # 2389172
$57.52 / Each
Weidmuller 2730440000 Key Features
Brand: Weidmuller
Part Number # 2730440000
SKU #2389172
Class: II
Dimensions: 45 mm H x 18 mm W x 64 mm D
Electrical Ratings: 120 VAC
Enclosure Type: IP20
Environmental Conditions: -40 to 85 deg C Operating/Storage Temperature, 5 to 95% Relative Humidity
Frequency Rating: 50/60 Hz
Modes of Protection: L-PE
Number of Poles: 1
Response Time: <=25 ns
Series: VPU Series
Short Circuit Current Rating (kA): 200 kA
Color: Orange
Country of origin: SI
Manufacturer Name: Weidmuller
UNSPSC: 39121634
UPC: 04050118807660
$57.52 / Each
Weidmuller 2730440000 VPU Series Surge Protection, Electrical Ratings: 120 VAC, 50/60 Hz, 1 Poles, 200 kA Short Circuit
Additional Description: WEID-2730440000 (N) VPU AC II US 0 120/50 SURGE VOLTAGE ARRESTER (POWER SUPPLY SYSTEMS), SURGE PROTECTION, TYPE II, II, AC, 120 V NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Device for surge protection in energy engineering and power supply. The device should be installed close to the feed-in of the system to be protected.
2730440000 Item Features
- 1 CO contact
- Unique multi-voltage input from 24 to 230 V UC
- Input voltages with coloured marking DC blue, UC white
- Due to high-quality design and no sharp edges no risk of injuries during installation
- Partition plates for optical separation and reinforcement of insulation
2730440000 Standards
RoHS Compliant|CE Certified|cULus Listed|VDESKU #2389172Part Number #2730440000UNSPSC39121634UPC04050118807660
