Part Number # 553280245030
SKU # 13031
Image Disclaimers Message
553280245030
Finder 553280245030
Part Number # 553280245030
SKU # 13031
$131.90 / 10Each
Typical price:$184.20 / Each
Finder 553280245030 Key Features
| Brand: | Finder |
|---|---|
| Part Number # : | 553280245030 |
| SKU #: | 13031 |
| Amperage Rating: | 10 A |
| Coil Voltage: | 24 V AC, 24 VAC |
| Contact Form: | 2CO 2 Form C DPDT, 2CO-DPDT |
| Contact Rating: | 250/400 V AC, 250/400 VAC |
| Dimensions: | 37.2 mm H x 27.7 mm W x 20.7 mm D |
| Display Type: | Mechanical |
| Frequency Rating: | 50/60 Hz |
| Number of Poles: | 2 |
| Series: | 55 |
| Temperature Rating (Degrees F): | -40 to 85 deg C |
| Terminal Type: | Plug-In |
| Country of origin: | IT |
| Mounting type: | Socket |
| Manufacturer Name: | FINDER |
| UNSPSC: | 39122326 |
| UPC: | 08012823107202 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$131.90 / 10Each
Typical price:$184.20 / Each
Quantity:
- Finder, 55.32.8.024.5030, Relay, Series: 55, 10 A, 1.5 VA Power, 50/60 Hz Frequency, 24 V AC Coil, 2CO 2 Form C DPDT Contact Form, 250/400 VAC Contact, 2 Pole, Socket Mounting, Plug-In Terminal, Mechanical Display, -40 to 85 deg C, 37.2 mm H x 27.7 mm W x 20.7 mm D Dimensions
553280245030 Application
Automation for blinds, grilles and shutters, Control and management of electric power, Shipyards, Road/tunnel lighting, Hoists and cranes, Circuit breakers and switche, Control panels, Panels for electrical distribution553280245030 Item Features
- AC or DC coil
- Lockable test button option and mechanical indicator as standard
- Variant with LED and integrated protection circuit
- For use with 94 Series sockets for printed circuit board, solder or for 35mm rail mount EN 60715 with push-in, screw or screwless terminals
- For use with 99 Series coil indication and EMC suppression modules and Type 86.30 timer modules
- Adaptors for alternative mount available
- Cadmium free contacts
553280245030 Standards
CE Marked|ANCE Marked|CCC Certified|CSA Certified|EAC Certified|IMQ Certified|LR Certified|RINA Certified|VDC Certified|cRUus Listed|UL ListedSKU #13031Part Number #553280245030UNSPSC39122326UPC08012823107202
