Part Number # 623282400000
SKU # 13086
Image Disclaimers Message
Brand: Finder
623282400000
Finder 623282400000
Part Number # 623282400000
SKU # 13086
$122.40 / 10Each
Typical price:$174.50 / Each
Finder 623282400000 Key Features
| Brand: | Finder |
|---|---|
| Part Number # : | 623282400000 |
| SKU #: | 13086 |
| Amperage Rating: | 16 A |
| Coil Voltage: | 240 VAC |
| Contact Form: | 2CO 2 Form C DPDT, 2CO/DPDT |
| Dimensions: | 35.8 mm W |
| Display Type: | LED |
| Enclosure Type: | RTI |
| Frequency Rating: | 50/60 Hz |
| Number of Poles: | 2 |
| Series: | 62 Series |
| Temperature Rating (Degrees F): | -40 to 70 deg C |
| Terminal Type: | 187 Faston/Socket |
| Type: | Standard |
| Mounting type: | Plug-In |
| Manufacturer Name: | FINDER |
| UNSPSC: | 39122324 |
| UPC: | 08012823255071 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$122.40 / 10Each
Typical price:$174.50 / Each
Quantity:
- Finder Power Relay, Standard, Series: 62 Series, 16 A, 2.2 VA Power, 50/60 Hz Frequency, 240 VAC Coil, 2CO 2 Form C DPDT Contact Form, 2 Poles, Plug-In Mounting, 187 Faston/Socket Terminal, LED Display, RTI Enclosure, -40 to 70 deg C, 35.8 mm W Dimensions
623282400000 Application
Road, Tunnel Lighting, Industrial Furnace, Oven, Burner, Boiler, Furnace, Control and Management of Electric Power, Punch, Cleaner, Planer, Sander, Control Panel, Circuit Breaker, Switch and Industrial Motor Applications623282400000 Item Features
- Mounting on 92 series socket or directly via 187 faston (4.8 x 0.5 mm)
- AC/DC coils
- LED, lockable test button and standard mechanical indicator
- Reinforced insulation between coil and contacts according to EN 60335-1, with 6 mm clearance and 8 mm creepage distance
- Variant with SELV separator between coil and contact
- Cadmium-free contact material
- Sockets and accessories
- European patent
- Standard AgCdO contact
623282400000 Standards
CCC Certified|CE Certified|cRUus Listed|CSA Certified|EAC Compliant|EC Certified|EN 60335-1|ENEC 03|IMQ Certified|RINA Approved|RoHS Compliant|UKCA Compliant|UL Listed|VDE ApprovedSKU #13086Part Number #623282400000UNSPSC39122324UPC08012823255071
