CSB500-2
Thomas & Betts CSB500-2
Part Number # CSB500-2
SKU # 2241580
$641.41 / 10Each
Typical price:$859.48 / Each
Thomas & Betts CSB500-2 Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | CSB500-2 |
| SKU #: | 2241580 |
| Conductor Type: | Aluminum/Copper/Stranded, Stranded Aluminum/Copper |
| Dimensions: | 2.71 in L x 3 in W x 2.75 in H |
| Series: | CSB |
| Specifications: | 3/8 in Hex Screw, 6 AWG to 500 kcmil Wire, Clear PVC Insulation, 6 AWG to 500 kcmil Wire, 3/8 in Hex Screw, Clear Color |
| Type: | 2-Way 2-Outlet Dual Rated Encapsulated, 2-Way 2-Outlet Encapsulated |
| Country of origin: | US |
| Material: | Aluminum |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121428 |
| UPC: | 00783786714988 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$641.41 / 10Each
Typical price:$859.48 / Each
Quantity:
- Homac Multi-Tap Cable Block, 2-Way 2-Outlet Dual Rated Encapsulated, Series: CSB, Stranded Aluminum/Copper Conductor, 600 V AC, Specifications: 3/8 in Hex Screw, 6 AWG to 500 kcmil Wire, Clear PVC Insulation, Aluminum, 2.71 in L x 3 in W x 2.75 in H
CSB500-2 Application
Commercial and Industrial ApplicationsCSB500-2 Item Features
- Versatile design
- Clear PVC insulation and safe and time-saving installation with no taping required
- Quick and easy-to install in the field
- Dual-rated for use with aluminum and copper conductors
- Above ground pedestal connectors and covers
- Wide range of cable sizes and number of outlets available in 1-way configurations
CSB500-2 Standards
ANSI C119.4|UL File No. E9809SKU #2241580Part Number #CSB500-2UNSPSC39121428UPC00783786714988
