Part Number # 750-652
SKU # 2260722
Image Disclaimers Message
Wago 750-652 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 750-652 |
| SKU #: | 2260722 |
| Baud rate: | 300 Baud … 115.2 kBd |
| Bit transfer: | RS-485/-422: ISO 8482 / DIN 66259 - 4; RS-232: EIA/TIA-232-F |
| Color: | Light gray |
| Connection technology: | 8 x CAGE CLAMP® |
| Country of origin: | DE |
| Depth: | 67.8 mm / 2.669 inch |
| Height: | 100 mm / 3.937 inch |
| Housing material: | Polycarbonate, polyamide 6.6 |
| Isolation: | 500 V system/field |
| Mounting position: | Horizontal (standing/lying); vertical |
| Mounting type: | DIN-35 rail |
| Number of data bits: | 7/8, adjustable |
| Number of stop bits: | 1/2, adjustable |
| Protection type: | IP20 |
| Signal type: | RS-232 || RS-422 / RS-485 |
| Solid conductor: | 0.08 … 2.5 mm² / 28 … 14 AWG |
| Vibration resistance: | 4g per IEC 60068-2-6 |
| Weight: | 50.264 g |
| Width: | 12 mm / 0.472 inch |
| UNSPSC: | 32151702 |
| UPC: | 04050821002949 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$739.84 / Each
Quantity:
Wago 750-652
Brand: Wago
Part Number: 750-652
Additional Description: WAGO-750-652 RS-232/485 SERIAL INTERFACE; LIGHT GRAY 7500652
Catalog Description: RS-232/485 Serial Interface
SKU #2260722Part Number #750-652UNSPSC32151702UPC04050821002949
