NBB8-18GM30-E3-V1
PEPPERL + FUCHS NBB8-18GM30-E3-V1
Part Number # NBB8-18GM30-E3-V1
SKU # 2268175
$125.17 / Each
PEPPERL + FUCHS NBB8-18GM30-E3-V1 Key Features
| Brand: | PEPPERL + FUCHS |
|---|---|
| Part Number # : | NBB8-18GM30-E3-V1 |
| SKU #: | 2268175 |
| Contact Configuration: | NC |
| Sensing Distance: | 8 mm |
| Sensing Method: | Inductive |
| Series: | F148P |
| Size: | 18 mm Dia x 45 mm L |
| Switching Speed: | 500 Hz |
| Type: | Tubular |
| Output type: | PNP |
| Manufacturer Name: | Pepperl+Fuchs |
| UNSPSC: | 39122230 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$125.17 / Each
Quantity:
- Pepperl+Fuchs Proximity Sensor, Tubular, Series: F148P, Inductive Sensing Method, 8 mm Sensing Distance, PNP Output, NC, 10/30 V DC, 100 mA, 500 Hz Switching Speed, 18 mm Dia x 45 mm L, -40 to 158 deg F, Flush Mount, Brass
NBB8-18GM30-E3-V1 Specifications
- Increased operating distance
- DC output polarity
- 0 to 6.48 mm (-13 to 158 deg F), 0 to 6.08 mm (-40 to -13 deg F) assured operating distance
- Reverse polarity protection
- Pulsing short-circuit protection
- LED, yellow switching state indicator
- 4-pin, M12 x 1 connector
- PBT sensing face
- IP67 degree of protection
- Nickel plated housing
NBB8-18GM30-E3-V1 Item Features
- Increased operating distance
- 0 to 6.48 mm (-13 to 158 deg F), 0 to 6.08 mm (-40 to -13 deg F) assured operating distance
- Reverse polarity protection
- Pulsing short-circuit protection
- LED, yellow switching state indicator
- 4-pin, M12 x 1 connector
- PBT sensing face
- IP67 degree of protection
- Nickel plated housing
- DC output polarity
NBB8-18GM30-E3-V1 Standards
cULus|cCSAus Listed|CCC CertifiedSKU #2268175Part Number #NBB8-18GM30-E3-V1UNSPSC39122230UPC
Image provided may only be a representation of final product and may include optional equipment
