Part Number # RV10-10Q
SKU # 2293946
Image Disclaimers Message
RV10-10Q
3M RV10-10Q
Part Number # RV10-10Q
SKU # 2293946
$108.40 / 10Pack
Typical price:$137.60 / Pack
3M RV10-10Q Key Features
| Brand: | 3M |
|---|---|
| Part Number # : | RV10-10Q |
| SKU #: | 2293946 |
| Temperature Rating (Degrees F): | -40 to 221, -40 to 221 deg F |
| Tongue Size: | 0.38 in W x 0.04 in THK |
| Tongue Type: | Ring |
| Type: | Insulated Standard |
| Color: | Yellow |
| Length: | 1.03, 1.03 in |
| Material: | Vinyl |
| Barrel Size: | 0.135 in ID x 0.25 in L |
| Barrel Type: | Butted Seam |
| Conductor Size: | 12 to 10, 12 to 10 AWG |
| Country of origin: | US |
| Finish: | Tin Plated |
| Manufacturer Name: | 3M |
| Specifications: | 1/4 in Dia Max Insulation, 0.29 in Clearance |
| UNSPSC: | 31200000 |
| UPC: | 00051128600320 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$108.40 / 10Pack
Typical price:$137.60 / Pack
Quantity:
- Highland, 7000133671, Terminal, Insulated, 12 to 10 AWG Conductor, #10 Stud, 1.03 in Length, Butted Seam Barrel, 0.135 in ID x 0.25 in L Barrel, Ring Tongue, 0.38 in W x 0.04 in THK Tongue, 600/1000 V AC, Specifications: 1/4 in Dia Max Insulation, 0.29 in Clearance, -40 to 221 deg F, Vinyl, Tin Plated, Yellow
RV10-10Q Application
Building Fixtures or Luminaires, Signs and Wire ApplicationsRV10-10Q Item Features
- Vinyl-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
- Funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires
- Standard-style ring tongue fits around the stud
- Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
- Withstands a temperature range of -40 to 221 deg F (-40 to 105 deg C)
RV10-10Q Standards
RoHS Compliant|UL File No. E23438|CSA File No. LR22190SKU #2293946Part Number #RV10-10QUNSPSC31200000UPC00051128600320
