Part Number # G111804
SKU # 2296167
Image Disclaimers Message
Belden G111804 Key Features
| Brand: | Belden |
|---|---|
| Part Number # : | G111804 |
| SKU #: | 2296167 |
| Conductor Size: | 18 AWG |
| Conductor Type: | Bare Stranded Copper |
| Jacket Color: | White |
| Jacket Material: | PVC |
| Number of Conductors: | 4 |
| Outside Diameter: | 0.169 in |
| Strands: | 7/26 |
| Temperature Rating (Degrees F): | 0 to 75 deg C |
| Type: | Type CMP/CL3P Multi-Conductor Shielded Plenum |
| Insulation material: | PVC |
| Length: | 500 ft |
| Manufacturer Name: | Omni Cable |
| UNSPSC: | 26121524 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
- Omni Cable Control Cable, Type CMP/CL3P Multi-Conductor Shielded Plenum, Reel Packaging, 300 V AC, 4 Conductors, Bare Stranded Copper Conductor, 18 AWG Conductor, 0.169 in OD, 500 ft Length, 7/26 Strands, PVC Insulation, PVC Jacket, White Jacket, 0 to 75 deg C
G111804 Application
For power limited control circuits, intercom, security, audio and background musicG111804 Item Features
- Overall Flexfoil polyester supported aluminum foil, stranded tinned copper drain wire shield
- Premium grade, color coded Flexguard PVC insulation
- Premium grade natural Flexguard PVC jacket
- Stranded or solid bare copper per ASTM B-3, B-8 and B-286 conductor
G111804 Standards
NFPA 262 Flame Test ApprovedSKU #2296167Part Number #G111804UNSPSC26121524UPC
