Brand: Weidmuller
Weidmuller 1634020000
Part Number # 1634020000
SKU # 2326078
Brand: Weidmuller
1634020000
Weidmuller 1634020000
Part Number # 1634020000
SKU # 2326078
$209.00 / 10Each
Typical price:$240.59 / Each
Weidmuller 1634020000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1634020000 |
| SKU #: | 2326078 |
| Connector Type: | Male Header |
| Dimensions: | 26.5 mm H x 87.5 mm W x 24.7 mm D |
| Number of Positions: | 46 |
| Series: | BL/SL 3.50 Series |
| Temperature Rating (Degrees F): | -50 to 100 deg C |
| Termination Type: | THT Solder |
| Type: | Board Connection |
| Contact material: | CuSn |
| Country of origin: | RO |
| Housing material: | PBT |
| Mounting type: | PCB |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 31163101 |
| UPC: | 04008190258474 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$209.00 / 10Each
Typical price:$240.59 / Each
Quantity:
- Weidmuller OMNIMATE Signal PCB Plug-In Connector, Board Connection, Series: BL/SL 3.50 Series, 46 Positions, 2 Rows, 3.5 mm Pitch/Row Spacing, PCB Mounting, 200/300 V, Male Header Connector, THT Solder Termination, CuSn Contact, PBT Housing Material, -50 to 100 deg C, Orange, 26.5 mm H x 87.5 mm W x 24.7 mm D Dimensions
1634020000 Item Features
- Two-tier pin header for wave soldering in 3.5 mm pitch
- The male connectors provide space for labeling and can be coded
- 200 V IEC, 300 V UL
1634020000 Standards
RoHS Compliant|IEC 60664-1, 61984|CSA No. 154685-1318353|UL 1059|UL No. E60693 Recognized|EAC Certified|UL 94 V-0 Flammability RatingSKU #2326078Part Number #1634020000UNSPSC31163101UPC04008190258474
Image provided may only be a representation of final product and may include optional equipment
