Part Number # CSB4-4S
SKU # 2359795
Image Disclaimers Message
CSB4-4S
Thomas & Betts CSB4-4S
Part Number # CSB4-4S
SKU # 2359795
$1061.35 / 25Each
Typical price:$1422.20 / Each
Thomas & Betts CSB4-4S Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | CSB4-4S |
| SKU #: | 2359795 |
| Conductor Type: | Aluminum/Copper/Stranded, Stranded Aluminum/Copper |
| Dimensions: | 2.12 in L x 1.25 in W x 1.25 in H |
| Series: | CSB |
| Specifications: | 14 to 4 AWG Wire, Clear Color, 14 to 4 AWG Wire, Clear PVC Insulation |
| Temperature Rating (Degrees F): | 90, 90 deg C |
| Type: | 1-Way 4-Outlet Dual Rated Encapsulated, 1-Way 4-Outlet Encapsulated |
| Country of origin: | US |
| Material: | Aluminum |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121428 |
| UPC: | 00783786714933 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1061.35 / 25Each
Typical price:$1422.20 / Each
Quantity:
- Homac Multi-Tap Cable Block, 1-Way 4-Outlet Dual Rated Encapsulated, Series: CSB, Stranded Aluminum/Copper Conductor, 600 VAC, Specifications: 14 to 4 AWG Wire, Clear PVC Insulation, 90 deg C, Aluminum, 2.12 in L x 1.25 in W x 1.25 in H
CSB4-4S Application
Commercial and Industrial ApplicationsCSB4-4S Item Features
- Versatile design
- Clear PVC insulation and safe and time-saving installation with no taping required
- Quick and easy to install in the field
- Dual rated for use with aluminum and copper conductors
- Slotted screw
- Wide range of cable sizes and number of outlets available in 1-way configurations
- Above ground pedestal connectors and covers
CSB4-4S Standards
ANSI C119.4|UL File No. E9809SKU #2359795Part Number #CSB4-4SUNSPSC39121428UPC00783786714933
