Part Number # T36EN13G7
SKU # 2375728
Image Disclaimers Message
T36EN13G7
Schneider Electric T36EN13G7
Part Number # T36EN13G7
SKU # 2375728
$1079.67 / Each
Typical price:$1185.00 / Each
Schneider Electric T36EN13G7 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | T36EN13G7 |
| SKU #: | 2375728 |
| Action: | Non-Reversing |
| Amperage Rating: | 90 A |
| Auxiliary Contact Rating: | 1NO |
| Coil Voltage: | 120 V AC, 120 VAC |
| Dimensions: | 6.57 in W x 6.96 in D x 11.91 in H |
| Enclosure Type: | Open |
| Frequency Rating: | 50/60 Hz |
| Motor Power: | 25 hp, 30 hp, 50 hp |
| Number of Poles: | 3 |
| Overload Relay: | Motor Logic 30 to 90 A Class 10/20 Solid State |
| Phase: | 3 |
| Series: | TeSys� N |
| Type: | Size 3 |
| Connection type: | Lug |
| Country of origin: | US |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121521 |
| UPC: | 03606486289686 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1079.67 / Each
Typical price:$1185.00 / Each
Quantity:
- Schneider Electric NEMA Motor Starter, Size 3, Series: TeSys N, 600 V AC, 90 A, 50/60 Hz Frequency, 25 hp, 30 hp, 50 hp Motor, 120 VAC Coil, 3 Poles, 3 ph, Lug Connection, Non-Reversing Action, Motor Logic 30 to 90 A Class 10/20 Solid State Overload Relay, 1NO Auxiliary, Open Enclosure, 6.57 in W x 6.96 in D x 11.91 in H Dimensions
T36EN13G7 Application
Material Handling an Hoisting ApplicationsT36EN13G7 Item Features
- High density, space saving design
- Common accessories across TeSys range to maximize convenience and reduce inventory
- Replaceable coils require no tools for easy installation
- Pre-mounted on a baseplate with busbar interconnection for quick, simple installation
- Snap-on front and side mount accessories for easy installation
- Common control circuit
- Without enclosure
- 25 hp at 200 VAC, 30 hp at 230 VAC, 50 hp at 460 VAC, 50 hp at 575 VAC
- https://youtu.be/Dm0SIlgwD-I
T36EN13G7 Standards
CSA Certified|CE Certified|UL Listed|RoHS Compliant|REACH Compliant|PROP65: Cancer and Reproductive Harm - www.P65Warnings.ca.govSKU #2375728Part Number #T36EN13G7UNSPSC39121521UPC03606486289686
