Part Number # C21601-02
SKU # 2388889
Image Disclaimers Message
Belden C21601-02 Key Features
| Brand: | Belden |
|---|---|
| Part Number # : | C21601-02 |
| SKU #: | 2388889 |
| Conductor Size: | 16 AWG |
| Conductor Type: | Stranded Copper |
| Jacket Color: | White |
| Number of Conductors: | 1 |
| Outside Diameter: | 0.08 in |
| Strands: | 19 |
| Temperature Rating (Degrees F): | 200 deg C |
| Type: | Type E |
| Insulation material: | PTFE |
| Manufacturer Name: | Omni Cable |
| UNSPSC: | 26121524 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
- Omni Cable Hook-Up Wire, Type E, 600 V AC, 1 Conductor, Stranded Copper Conductor, 16 AWG Conductor, 0.08 in OD, 19 Strands, PTFE Insulation, White Jacket, 200 deg C
C21601-02 Application
For power and control use in power plants and other operations where wire is exposed to acids, oils, moisture, high temperature and military harnessingC21601-02 Item Features
- 50 ft minimum lengths no more than 5 lengths per 1000 ft, 50 ft minimum lengths no more than 12 per 5000 ft
- Silver-plated stranded copper conductor
C21601-02 Standards
UL Listed|MIL-W-16878/4 SpecifiedSKU #2388889Part Number #C21601-02UNSPSC26121524UPC
