Part Number # SPD2-350-M
SKU # 2423157
Image Disclaimers Message
Littelfuse SPD2-350-M Key Features
| Brand: | Littelfuse |
|---|---|
| Part Number # : | SPD2-350-M |
| SKU #: | 2423157 |
| Class: | Class II |
| Dimensions: | 0.71 in W x 2.25 in D x 1.77 in H |
| Electrical Ratings: | 350 VAC |
| Enclosure Type: | IP20 |
| Environmental Conditions: | 5 to 95% Humidity, 40 to 185 deg F Temperature |
| Frequency Rating: | 50/60 Hz |
| Indicator Type: | Green/Not Green |
| Modes of Protection: | L-N, N-PE |
| Number of Outlets: | 1 |
| Response Time: | <25 ns |
| Series: | SPD2 1P+1 Series |
| Short Circuit Current Rating (kA): | 25/50 kA |
| Terminal Type: | Screw |
| Type: | Type 2 CA Pluggable |
| Country of origin: | SI |
| Material: | Thermoplastic |
| Mounting type: | DIN Rail |
| Manufacturer Name: | Littelfuse |
| UNSPSC: | 39121610 |
| UPC: | 00079458253764 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
- Littelfuse Surge Protection Device Module, Type 2 CA Pluggable, Series: SPD2 1P+1 Series, 350 VAC Electrical Rating, 50/60 Hz Frequency, 25/50 kA Short Circuit, 1750/1500 V Clamping, 20/40 kA Nominal Discharge, Modes of Protection: L-N, N-PE, 1 Outlets, <25 ns Response, Green/Not Green Indicator, Class: Class II, Environmental Conditions: 5 to 95% Humidity, 40 to 185 deg F Temperature, IP20 Enclosure, DIN Rail Mounting, Screw Terminal, Thermoplastic, 0.71 in W x 2.25 in D x 1.77 in H Dimensions
SPD2-350-M Application
For equipment protection from transient over voltagesSPD2-350-M Item Features
- Capability to clamp and withstand high energy transients - ensures low residual voltage during high energy surge events and higher nominal discharge current to prevent disruption, downtime and degradation or damage to equipment
- One component can be utilized globally, reducing inventory needs and simplifying allocation of parts
- Interlocking tab - mechanism secures module to withstand vibration
- No additional overcurrent protection devices required in UL applications - reduces the number of components and costs required for protection
- Compact footprint - increases panel design flexibility
- Visual life indicator - quick visual determines module replacement status to avoid loss of protection
- Pluggable modules - fast and simple to replace, minimizing maintenance and downtime, no tools required
- Thermal protection - eliminates catastrophic failure
- IP20 protection rating - finger safe design increases worker protection
- 25 kA/50 kA (IEC) and 200 kA (UL) short circuit current
- 1750/1500 V (IEC)/350/305 V (UL) Voltage protection
SPD2-350-M Standards
cULus Recognized|CE Certified|E320116|IEC 61643-11:2011|EN 61643-11:2012|UL 1449|VDE/IEC CompliantSKU #2423157Part Number #SPD2-350-MUNSPSC39121610UPC00079458253764
