Part Number # BJ11403
SKU # 2427631
Image Disclaimers Message
Brand: Belden
BJ11403
Belden BJ11403
Part Number # BJ11403
SKU # 2427631
$1.05 / Feet
Typical price:$1.20 / Feet
Belden BJ11403 Key Features
| Brand: | Belden |
|---|---|
| Part Number # : | BJ11403 |
| SKU #: | 2427631 |
| Amperage Rating: | 18 A |
| Conductor Size: | 14 AWG |
| Conductor Type: | Annealed Bare Copper |
| Jacket Color: | Black |
| Jacket Material: | CPE |
| Number of Conductors: | 3 |
| Outside Diameter: | 0.37 in |
| Strands: | 41/30 |
| Temperature Rating (Degrees F): | 90 deg C |
| Type: | Type SJOOW Flexible |
| Insulation material: | EPDM |
| Manufacturer Name: | Omni Cable |
| UNSPSC: | 26121603 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1.05 / Feet
Typical price:$1.20 / Feet
Quantity:
- Omni Cable Portable Cord, Type SJOOW Flexible, 300 V AC, 18 A, 3 Conductors, Annealed Bare Copper Conductor, 14 AWG Conductor, 0.37 in OD, 41/30 Strands, EPDM Insulation, CPE Jacket, Black Jacket, 90 deg C
BJ11403 Application
For hard usage with portable tools, small motors and power extensions and is sunlight, water, oil and weather resistant and outdoor applicationsBJ11403 Item Features
- Bare, annealed copper per ASTM B-3 flexible, bunch-stranded per UL-62
- Color coded synthetic rubber (EPDM) oil and water-resistant per UL-62
- Conductors are assembled round with fillers as needed and a separator is applied over the assembly
- Often referred to as service cord
BJ11403 Standards
UL Listed|CSA Certified|CE Marked|RoHS Compliant|PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.govSKU #2427631Part Number #BJ11403UNSPSC26121603UPC
