Part Number # CR306B002
SKU # 2435411
Image Disclaimers Message
CR306B002
ABB CR306B002
Part Number # CR306B002
SKU # 2435411
$431.63 / Each
Typical price:$816.00 / Each
ABB CR306B002 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | CR306B002 |
| SKU #: | 2435411 |
| Amperage Rating: | 18 A |
| Coil Voltage: | 115 to 120 V AC, 115 to 120 VAC |
| Dimensions: | 9 in L x 6-1/4 in W x 5-5/8 in H |
| Enclosure Type: | Open |
| Frequency Rating: | 50/60 Hz |
| Number of Poles: | 3 |
| Operating Temperature: | -20 to 70 deg C |
| Overload Relay: | 3-Leg Block/Thermal |
| Reset Type: | Manual |
| Series: | 300 Line |
| Type: | Full Voltage Non-Combination Non-Reversing |
| Connection type: | Saddle Clamp |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121521 |
| UPC: | 00783166353615 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$431.63 / Each
Typical price:$816.00 / Each
Quantity:
- GE NEMA Magnetic Starter, Full Voltage Non-Combination Non-Reversing, Series: 300 Line, 600 V AC, 18 A, 50/60 Hz Frequency, 115 to 120 VAC Coil, 3 Pole, Manual Reset, Saddle Clamp Connection, 3-Leg Block/Thermal Overload Relay, Open Enclosure, -20 to 70 deg C Operating, 9 in L x 6-1/4 in W x 5-5/8 in H Dimensions
CR306B002 Application
Motor Control Centers, Electrical Distribution and Control ApplicationsCR306B002 Includes
Holding Interlock, Pressure Terminals and Overload RelayCR306B002 Item Features
- Has an encapsulated coil and a 3 leg overload relay to protect against overloads in all phases
- Toolless contactor disassembly allows quick access for inspection and maintenance
- Current carrying contact tips are weld resistant silver cadmium oxide
- Visual trip indicator with manual reset to avoid surprise restarts
- Manual weld check provides a convenient test against welding of overload relay contacts
- 2:1 adjustable full load amps with tactile feedback dial
- Built-in thermal memory to prevent hot motor restarts
- Protection against complete phase current loss
- +/- 2% accuracy, +/- 2% repeatability, Self-powered at 50% of minimum current range
- Saddle clamp terminal accommodate ring, spade and stripped wire leads and carry permanent stamped in identification
CR306B002 Standards
ARRA Compliant|Buy American Act Compliant|RoHS CompliantSKU #2435411Part Number #CR306B002UNSPSC39121521UPC00783166353615
