Part Number # 2002-1701
SKU # 2440748
2002-1701
Wago 2002-1701
Part Number # 2002-1701
SKU # 2440748
Wago 2002-1701 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2002-1701 |
| SKU #: | 2440748 |
| Amperage Rating: | 16 A |
| Dimensions: | 3.024 in H x 0.205 in W x 1.555 in D |
| Number of Poles: | 1 |
| Type: | Operating Tool |
| Wire Size: | 22 to 12 AWG |
| Connection type: | Clamp |
| Material: | Polyamide |
| Mounting type: | 35 mm DIN Rail, DIN Rail |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04050821707486 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Wago 2002-1701
Brand: Wago
Part Number: 2002-1701
Additional Description: WAGO-2002-1701 3-CONDUCTOR THROUGH TERMINAL BLOCK; 2.5 MM; WITH TEST OPTION; SAME PROFILE AS 3-CONDUCTOR DISCONNECT TERMINAL BLOCK; SIDE AND CENTER MARKING; FOR DIN-RAIL 35 X 15 AND 35 X 7.5; PUSH-IN CAGE CLAMP; 2,50 MM; GRAY 60402028
Catalog Description: 3-conductor through terminal block; 2.5 mm²; with test option; same profile as 3-conductor disconnect terminal block; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; Push-in CAGE CLAMP®; 2,50 mm²; gray
2002-1701 Standards
CSA 22.2 No 158|ATEX: KIWA 17 ATEX 0030 U / IECEx: KIWA 17.0014U (Ex ec IIC Gc)|RoHS CompliantSKU #2440748Part Number #2002-1701UNSPSC39121410UPC04050821707486
Image provided may only be a representation of final product and may include optional equipment
