2639730000
Weidmuller 2639730000
Part Number # 2639730000
SKU # 2444080
$330.40 / 10Each
Typical price:$354.50 / Each
Weidmuller 2639730000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 2639730000 |
| SKU #: | 2444080 |
| Amperage Rating: | 6 A |
| Coil Voltage: | 24 V DC |
| Contact Form: | 1CO 1 Form C SPDT |
| Dimensions: | 6.4 mm W x 88 mm D x 90 mm H |
| Display Type: | Green/Orange LED |
| Electrical Connections: | Push-In |
| Enclosure Type: | IP20 |
| Operation Mode: | 3-Function |
| Series: | TERMSERIES |
| Temperature Rating (Degrees F): | -20 to 60 deg C |
| Time Setting: | 0.01 to 100 s |
| Country of origin: | CN |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 39122325 |
| UPC: | 04050118797916 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$330.40 / 10Each
Typical price:$354.50 / Each
Quantity:
- Weidmuller Timing Relay, Series: TERMSERIES, Operation Mode: 3-Function, 6 A, 1CO 1 Form C SPDT Contact Form, 0.01 to 100 s Time Setting, 24 V DC Coil, 50 ms Pulse, Green/Orange LED Display, Push-In Electrical Connections, IP20 Enclosure, -20 to 60 deg C, DIN Rail Mounting, 6.4 mm W x 88 mm D x 90 mm H Dimensions
2639730000 Item Features
- Simple setting of timing functions and time ranges
- Integrated status LED (duo LED in the ejection lever) for power supply and switching status
- Without test button and mechanical switch position indicator
2639730000 Standards
CE Certified|cULus File No.E141197|EAC Compliant|EN 61812-1:2011|UL 61010-1|UL 94 Flammability Rating V-0SKU #2444080Part Number #2639730000UNSPSC39122325UPC04050118797916
Image provided may only be a representation of final product and may include optional equipment
