Part Number # T58SST-TB
SKU # 2444119
Image Disclaimers Message
T58SST-TB
Thomas & Betts T58SST-TB
Part Number # T58SST-TB
SKU # 2444119
$661.78 / Each
Typical price:$886.78 / Each
Thomas & Betts T58SST-TB Key Features
| Brand: | Thomas & Betts |
|---|---|
| Part Number # : | T58SST-TB |
| SKU #: | 2444119 |
| Capacity: | 45 cu-in |
| Dimensions: | 10.046 in L x 3.867 in D |
| Finish: | Polished |
| Form: | Form 8 |
| Hub Size: | 1-1/2 in |
| Series: | T Series |
| Connection type: | NPT |
| Country of origin: | TH |
| Material: | 316 Stainless Steel |
| Manufacturer Name: | ABB |
| UNSPSC: | 39131708 |
| UPC: | 00786210224084 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$661.78 / Each
Typical price:$886.78 / Each
Quantity:
- T&B Conduit Body, Series: T Series, 1-1/2 in Hub, 45 cu-in Capacity, Form 8 Form, NPT Connection, 316 Stainless Steel, Polished, 10.046 in L x 3.867 in D Dimensions
T58SST-TB Application
Food and Beverage, Pharmaceutical, Petrochemical, Wastewater Treatment, Pulp and Paper Processing and Other Corrosive EnvironmentsT58SST-TB Item Features
- Marine grade type 316 stainless steel construction in rugged form 8 design
- Radius is the same as bent conduit, so you can pull wire through the body
- Angled cover port enables easier wire pulling and uses standard covers
- Tapered (NPT) threads and integral bushings to protect wire insulation
- Rated for 40% wire fill
- Connect conduit sections
- Act as pull outlets when conductors are being installed
- Provide easy access for splices in branch conductors
- Make 90 deg bends in conduit runs
- Act as mounting outlets for wiring devices and light fixtures
- Provide access to conductors for maintenance and future system changes
T58SST-TB Standards
UL Listed|CSA CertifiedSKU #2444119Part Number #T58SST-TBUNSPSC39131708UPC00786210224084
