Part Number # MC1I-3-10-AT-D
SKU # 2444675
Image Disclaimers Message
Brand: ABB
MC1I-3-10-AT-D
ABB MC1I-3-10-AT-D
Part Number # MC1I-3-10-AT-D
SKU # 2444675
$173.91 / Each
ABB MC1I-3-10-AT-D Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | MC1I-3-10-AT-D |
| SKU #: | 2444675 |
| Coil Power Rating: | 3 hp, 5 hp, 1/2 hp, 1-1/2 hp |
| Coil Voltage: | 24 V DC, 24 VDC |
| Contact Configuration: | 1NO |
| Dimensions: | 1.89 in H x 3.46 in D |
| Enclosure Type: | IP20 |
| Number of Poles: | 3 |
| Operating Temperature: | -4 to 131 deg F |
| Series: | C-2000/M Series |
| Terminal Type: | Screw |
| Wattage: | 1.2 kW |
| Mounting type: | DIN Rail |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121529 |
| UPC: | 04013614542732 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$173.91 / Each
Quantity:
- GE Mini-Contactor, Series: C-2000/M Series, 24 V DC Coil, 9 A Maximum Load Current, 3 hp, 5 hp, 1/2 hp, 1-1/2 hp Coil, 3 Pole, 1.2 kW Wattage, Non-Reversing Contact, 1NO Contact Configuration, Screw Terminal, IP20 Enclosure, -4 to 131 deg F Operating, DIN Rail Mounting, 1.89 in H x 3.46 in D Dimensions
MC1I-3-10-AT-D Application
Electrical Distribution and Control ApplicationsMC1I-3-10-AT-D Item Features
- Screws and fast-on terminals protected against accidental contact in accordance with VDE 0106 T.100 and VBG4
- Facility to mount instant and timed auxiliary contact blocks and voltage suppressor block
- 3 hp at 200 to 208 VAC 60 Hz 3 ph, 3 hp at 220 to 240 VAC 60 Hz 3 ph, 5 hp at 460 to 480 VAC 60 Hz 3 ph, 5 hp at 550 to 600 VAC 60 Hz 3 ph, 1/2 hp at 115 VAC 60 Hz 1 ph, 1-1/2 hp at 230 VAC 60 Hz 1 ph coil power rating
MC1I-3-10-AT-D Standards
ARRA Compliant|Buy American Act Compliant|RoHS Compliant|cULus Listed|CE Certified|SETI|IMQ|Lloyds Register|Bureau Veritas|RINA|IEC/EN 60947-1|IEC/EN 60947-4-1|IEC/EN 60947-5-1|EN 50005|EN 50003|EN 50012|UL 508|NEMA ICS-1|BS 4794|CSA 22.2/14|NFC 63-110|SEV 10254|JIS C8325|JEM 1038|VDE 0660|CENELEC HD 419SKU #2444675Part Number #MC1I-3-10-AT-DUNSPSC39121529UPC04013614542732
