Part Number # 3-520276-2
SKU # 2448961
Image Disclaimers Message
TE Connectivity 3-520276-2 Key Features
| Brand: | TE Connectivity |
|---|---|
| Part Number # : | 3-520276-2 |
| SKU #: | 2448961 |
| Barrel Type: | Closed |
| Conductor Size: | 16 to 14 AWG |
| Dimensions: | 0.935 in L |
| Finish: | TiN Coated |
| Insulated: | No |
| Series: | Ultra-Fast 187 |
| Specifications: | Straight |
| Temperature Rating (Degrees F): | -40 to 230 deg F |
| Terminal Type: | Receptacle |
| Color: | Blue |
| Country of origin: | US |
| Material: | Brass |
| Manufacturer Name: | TE Connectivity |
| UNSPSC: | 39121410 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
- TE Connectivity Quick Disconnect, Series: Ultra-Fast 187, 16 to 14 AWG Conductor, 0.187 in W x 0.032 in THK Tab, Closed Barrel, Receptacle TE Connectivityrminal, 600 V, Specifications: Straight, -40 to 230 deg F, Brass, Blue, TiN CoaTE Connectivityd, 0.935 in L, InsulaTE Connectivityd: No
3-520276-2 Standards
China RoHS 2 Directive MIIT Order No 32, 2016|EU RoHS Directive 2011/65/EU|EU ELV Directive 2000/53/EC|UL File No. 94V-2SKU #2448961Part Number #3-520276-2UNSPSC39121410UPC
