Part Number # 769-606/006-000
SKU # 2455377
769-606/006-000
Wago 769-606/006-000
Part Number # 769-606/006-000
SKU # 2455377
$11.87 / Each
Typical price:$12.86 / Each
Wago 769-606/006-000 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 769-606/006-000 |
| SKU #: | 2455377 |
| Amperage Rating: | 32 A |
| Dimensions: | 1.181 in H x 1.744 in W x 1.642 in D |
| Number of Poles: | 6 |
| Temperature Rating (Degrees F): | -35 to 85 deg C |
| Type: | Operating Tool |
| Wire Size: | 28 to 12 AWG |
| Connection type: | Clamp |
| Material: | Polyamide |
| Mounting type: | Flange/Snap-In |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04045454917036 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$11.87 / Each
Typical price:$12.86 / Each
Quantity:
Wago 769-606/006-000
Brand: Wago
Part Number: 769-606/006-000
Additional Description: WAGO-769-606/006-000 1-CONDUCTOR MALE CONNECTOR; SNAP-IN FLANGE; 4 MM ; PIN SPACING 5 MM; 6-POLE; 4,00 MM ; GRAY 51217798
Catalog Description: 1-conductor male connector; CAGE CLAMP®; 4 mm²; Pin spacing 5 mm; 6-pole; Snap-in flange; 4,00 mm²; gray
769-606/006-000 Standards
RoHS CompliantSKU #2455377Part Number #769-606/006-000UNSPSC39121410UPC04045454917036
Image provided may only be a representation of final product and may include optional equipment
