Part Number # M9L53690
SKU # 2456355
Image Disclaimers Message
M9L53690
Schneider Electric M9L53690
Part Number # M9L53690
SKU # 2456355
$228.73 / Each
Typical price:$247.56 / Each
Schneider Electric M9L53690 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | M9L53690 |
| SKU #: | 2456355 |
| Dimensions: | 3.61 in H x 2.07 in W x 2.81 in D |
| Electrical Ratings: | 10 kA |
| Enclosure Type: | NEMA 1 |
| Environmental Conditions: | -40 to 185 deg F |
| Number of Poles: | 3 |
| Number of Wires: | 4 |
| Peak Surge Current: | 10 kA |
| Response Time: | 25 ns |
| Series: | Multi 9 |
| Short Circuit Current Rating (kA): | 200 kA |
| Terminal Type: | Tunnel |
| Type: | Surge Arrester |
| Color: | Gray |
| Country of origin: | FR |
| Mounting type: | DIN Rail |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121603 |
| UPC: | 03606481585981 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$228.73 / Each
Typical price:$247.56 / Each
Quantity:
Schneider Electric M9L53690
Brand: Schneider Electric
Part Number: M9L53690
Additional Description: SQD -M9L53690 MULTI9 PRD1 75R 3P T1 400/690V SPD
Catalog Description: surge arrester, Multi9 PRD1 75r, 3P, 400/690 V
M9L53690 Item Features
- Multi 9 is a range of DIN rail modular devices, a solution offering great performance
- Multi 9 range is a Schneider Electric global offer dedicated to equipment manufacturers (OEMs), meeting all global standards for industry applications
- Designed to meet your needs for all types of machines and offering a wide range of modular devices, it provides protection, signaling functions, and accessories
- Small footprint to reduce your panel size, cost effective, less commercial references
- With remote signalling
- Electrical distribution network surge arrester type
- Type 1 surge arrester class type
- MOV surge arrester technology
- 75 kA maximum discharge current
- 75 kA iimp impulse current
- Common mode 550 V AC L/NDifferential mode 1100 V AC L/L uc maximum continuous operating voltage
- <1500 V L/N <3000 V L/L maximum up voltage protection level
- Associated circuit breaker disconnector device type
- 200 kA short-circuit withstand
- 6 9 mm pitches
- 0.39 in (10 mm) L/N 0.39 in (10 mm) PE 0.24 in (6 mm) dry contacts wire stripping length
M9L53690 Standards
UL 1449:ed. 4SKU #2456355Part Number #M9L53690UNSPSC39121603UPC03606481585981
