Part Number # NCB5-18GM40-N0-5M
SKU # 2465945
NCB5-18GM40-N0-5M
Pepperl+Fuchs NCB5-18GM40-N0-5M
Part Number # NCB5-18GM40-N0-5M
SKU # 2465945
$146.72 / Each
Pepperl+Fuchs NCB5-18GM40-N0-5M Key Features
| Brand: | Pepperl+Fuchs |
|---|---|
| Part Number # : | NCB5-18GM40-N0-5M |
| SKU #: | 2465945 |
| Contact Configuration: | NC |
| Sensing Distance: | 5 mm |
| Sensing Method: | Inductive |
| Series: | Comfort |
| Size: | 18 mm Dia x 40 mm L |
| Switching Speed: | 400 Hz |
| Temperature Rating (Degrees F): | -13 to 212 deg F |
| Type: | Tubular |
| Output type: | NAMUR |
| Manufacturer Name: | Pepperl+Fuchs |
| UNSPSC: | 0 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$146.72 / Each
Quantity:
- Pepperl+Fuchs Proximity Sensor, Tubular, Series: Comfort, Inductive Sensing Method, 5 mm Sensing Distance, NAMUR Output, NC, 8 V DC, Cable, 400 Hz Switching Speed, 18 mm Dia x 40 mm L, -13 to 212 deg F, Flush Mount, Stainless Steel
NCB5-18GM40-N0-5M Item Features
- 0 to 4.05 mm assured operating distance, 4.5 to 5.5 mm actual operating distance
- 5 m PVC cable connection
- 0.75 sq-mm core cross-section
- PBT sensing face
- IP67 degree of protection
- >10 x cable diameter bending radius
- <=1 mA measuring plate detected, 3 mA measuring plate not detected
- LED, yellow switching state indicator
- -40 to 212 deg F storage temperature
- Reverse polarity protection
- Equipment protection level DC (tc)
- 2-wire AC output polarity
- Short-circuit protection
NCB5-18GM40-N0-5M Standards
cULus|cCSAus Listed|CCC CertifiedSKU #2465945Part Number #NCB5-18GM40-N0-5MUNSPSC0UPC
Image provided may only be a representation of final product and may include optional equipment
