Part Number # MG24532
SKU # 45344
Image Disclaimers Message
Brand: Schneider Electric
MG24532
Schneider Electric MG24532
Part Number # MG24532
SKU # 45344
$258.39 / Each
Typical price:$315.00 / Each
Schneider Electric MG24532 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | MG24532 |
| SKU #: | 45344 |
| Actuator Type: | Toggle |
| Amperage Rating: | 1, 1 A |
| Dimensions: | 2.87 in L x 2.13 in W x 3.19 in H, 3.19 in H x 2.13 in W x 2.87 in D |
| Enclosure Type: | IP20/IP40 |
| Frequency Rating: | 50/60, 50/60 Hz |
| Interrupt Rating: | 10 kA at 240 VAC, 6 kA at 440 VAC, 10 kA at 415 VAC, 6 |
| Number of Poles: | 3 |
| Series: | C60 |
| Temperature Rating (Degrees F): | -22 to 158, -30 to 70, -30 to 70 deg C |
| Trip Type: | D-Curve/Thermal Magnetic, Thermal Magnetic |
| Wire Size: | 14 to 4, 14 to 4 AWG |
| Connection type: | Tunnel |
| Country of origin: | FR |
| Mounting type: | DIN Rail |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121603 |
| UPC: | 00785901881315 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$258.39 / Each
Typical price:$315.00 / Each
Quantity:
- Schneider Electric Multi 9 Miniature Circuit Breaker, Series: C60, 240/415/440 VAC, 1 A, 50/60 Hz Frequency, 10 kA at 240 VAC, 6 kA at 440 VAC, 10 kA at 415 VAC Interrupt, Thermal Magnetic Trip, 3 Pole, Toggle Actuator, Tunnel Connection, 14 to 4 AWG Wire, IP20/IP40 Enclosure, DIN Rail Mounting, -30 to 70 deg C, 2.87 in L x 2.13 in W x 3.19 in H Dimensions, Gray
MG24532 Specifications
- 10 kA at 240 VAC, 6 kA at 440 VAC, 10 kA at 415 VAC, 20 kA at 240 VAC, 6 kA at 440 VAC, 10 kA at 415 VAC, 20 kA at 240 VAC, 5 kA at 480Y/277 VAC, 10 kA at 240 VAC, 5 kA at 480Y/277 VAC
- ON/OFF indication
- (6) 9 mm pitches
MG24532 Application
For distribution, supplementary protectors to provide overcurrent protection within appliances or electrical equipmentMG24532 Item Features
- Trip-free mechanism contacts cannot be held in the On position when the C60 is tripped automatically
- Positive indication of contact disconnect
- Green mechanical indication on front face of circuit breaker shows that all poles are open
- Overcurrent protection for loads with high inrush currents (motors, transformers)
- Magnetic release operates between 10 and 14 times ampere rating (no DC rating for D curve)
- Allows locking in On/Off position using padlock attachment
- Suitable for reverse feeding
MG24532 Standards
RoHS Compliant|UL 1077 File No. E90509|CSA C22.2 No. 235 File No. 179014|IEC 60947-2|CE Marked|eccn: EAR99SKU #45344Part Number #MG24532UNSPSC39121603UPC00785901881315
