Part Number # MG24426
SKU # 93876
Image Disclaimers Message
Brand: Schneider Electric
MG24426
Schneider Electric MG24426
Part Number # MG24426
SKU # 93876
$994.20 / 12Each
Typical price:$1212.00 / Each
Schneider Electric MG24426 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | MG24426 |
| SKU #: | 93876 |
| Actuator Type: | Toggle |
| Amperage Rating: | 2, 2 A |
| Color: | Gray |
| Connection type: | Tunnel |
| Country of origin: | FR |
| Dimensions: | 73 mm L x 18 mm W x 81 mm H |
| Enclosure Type: | IP20/IP40 |
| Frame: | M |
| Frequency Rating: | 50/60, 50/60 Hz |
| Interrupt Rating: | 3/10, 3/10 kA |
| Mounting type: | DIN Rail |
| Number of Poles: | 1 |
| Temperature Rating (Degrees F): | -22 to 158, -22 to 158 deg F |
| Trip Type: | Thermal Magnetic, Thermal Magnetic/C-Curve |
| Type: | Miniature Standard |
| Wire Size: | 14 to 4, 14 to 4 AWG |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121603 |
| UPC: | 00785901346159 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$994.20 / 12Each
Typical price:$1212.00 / Each
Quantity:
- Schneider Electric Multi 9 Supplementary Protector, Miniature Standard, 240/415 VAC, 60 VDC, 2 A, 50/60 Hz Frequency, 3/10 kA Interrupt, M Frame, Thermal Magnetic Trip, 1 Pole, Toggle Actuator, Tunnel Connection, 14 to 4 AWG Wire, IP20/IP40 Enclosure, DIN Rail Mounting, -22 to 158 deg F, 73 mm L x 18 mm W x 81 mm H Dimensions, Gray
MG24426 Specifications
- Trip free mechanism contacts cannot be held in the on position when the C60 is tripped automatically
- IP20 conforming to IEC 60529-IP40 for modular enclosure conforming to IEC 60529
- Positive indication of contact disconnect, green mechanical indication on front face of device shows that all poles are open
- Allows locking in ON-OFF position using padlock attachment
- Suitable for reverse feeding
- C curve - magnetic setting between 7 and 10 times ampere rating (7 and 14 for DC)
- 14 to 4 AWG copper
- 10 kA at 120/240 VAC, 5 kA at 277 VAC, 10 kA at 60 VDC
- 35 mm DIN-rail mounting
- Frame size C100N/63 A
MG24426 Application
For overcurrent protection within appliances or electrical equipmentMG24426 Item Features
- Trip free mechanism contacts cannot be held in the on position when the C60 is tripped automatically
- Positive indication of contact disconnect, green mechanical indication on front face of device shows that all poles are open
- Allows locking in ON-OFF position using padlock attachment
- Suitable for reverse feeding
- C curve - magnetic setting between 7 and 10 times ampere rating (7 and 14 for DC)
- 14 to 4 AWG copper
- 10 kA at 120/240 VAC, 5 kA at 277 VAC, 10 kA at 60 VDC
- 35 mm DIN-rail mounting
- Frame size C100N/63 A
- IP20 conforming to IEC 60529-IP40 for modular enclosure conforming to IEC 60529
MG24426 Standards
ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL 1077/C60|GB 14048.2|EN/IEC 60947-2|CSA C22.2 No 235|CCC Certified|IEC 60947-2/60529|UR Certified|eccn:EAR99SKU #93876Part Number #MG24426UNSPSC39121603UPC00785901346159
