ABB 1SVR405611R2100 Miniature Interface Relay
Part Number # 1SVR405611R2100
SKU # 2216966
$115.80 / 10Each
$213.10/Each
Only 9 left in stock order soon
Ships in 1 Business Day
ABB 1SVR405611R2100 Key Features
Brand: ABB
Part Number # 1SVR405611R2100
SKU #2216966
Amperage Rating: 12, 5, 5 mA
Coil Voltage: 120, 120 VAC
Contact Form: 2CO DPDT, 2CO/DPDT
Contact Rating: 12 A at 250 VAC
Dimensions: 35.6 mm H x 21.2 mm W x 27.5 mm D
Display Type: LED
Enclosure Type: IP40
Frequency Rating: 50/60, 50/60 Hz
Number of Poles: 2
Power Rating: 0.3, 0.3 W
Series: CR, CR-M
Temperature Rating (Degrees F): -40 to 55, -40 to 55 deg C, -40 to 70
Terminal Type: Cage Clamp/Fork/Screw
Type: General Purpose, General Purpose Pluggable
Country of origin: LT
Mounting type: PCB, Socket
Manufacturer Name: ABB
UNSPSC: 39122331
UPC: 04013614497254
$115.80 / 10Each
$213.10/Each
ABB 1SVR405611R2100 Miniature Interface Relay
Brand: ABB
Part Number: 1SVR405611R2100
ABB Miniature Interface Relay, General Purpose Pluggable, Series: CR, 5 mA, 0.3 W Power, 50/60 Hz Frequency, 120 VAC Coil, 2CO/DPDT Contact Form, 12 A at 250 VAC Contact, Socket Mounting, IP40 Enclosure, -40 to 55 deg C, 35.6 mm H x 21.2 mm W x 27.5 mm D Dimensions
Additional Description: ABB -1SVR405611R2100 (N) CR-M120AC2L PLUGGABLE INTERFACE REL NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Plugin control relay with 120 VAC rated control supply voltage, DPDT (2 c/o) contacts, contacts, with LED indicator and 250 V, 12 A contact rating
1SVR405611R2100 Application
For 3PDT plug-in control relays1SVR405611R2100 Item Features
- Standard miniature relays with mechanical status indication
- The relay has an integrated blue test button for manual actuation and locking of the output contacts
- Suited for logical and standard sockets
- Cadmium free contact
- Pluggable function modules - reverse polarity protection/free wheeling diode, LED indication, RC elements, overvoltage protection, time modules
1SVR405611R2100 Standards
CE Marked|CSA Certified|GOST|RoHS Compliant|RoHS Compliant|UL Listed|CE|CSA|GOST CertifiedSKU #2216966Part Number #1SVR405611R2100UNSPSC39122331UPC04013614497254
