ABB 1SVR405611R7100 Miniature Interface Relay
Part Number # 1SVR405611R7100
SKU # 2223534
$125.10 / 10Each
ABB 1SVR405611R7100 Key Features
Brand: ABB
Part Number # 1SVR405611R7100
SKU #2223534
Amperage Rating: 5, 5 mA
Coil Voltage: 110, 110 VAC
Contact Form: 2CO-SPDT, 2CO/SPDT
Contact Rating: 12 A at 250 VAC
Dimensions: 35.6 mm H x 21.2 mm W x 27.5 mm D
Enclosure Type: IP40
Frequency Rating: 50/60, 50/60 Hz
Power Rating: 0.3, 0.3 W
Series: CR
Temperature Rating (Degrees F): -40 to 55, -40 to 55 deg C
Type: General Purpose Pluggable
Country of origin: LT
Mounting type: Socket
Manufacturer Name: ABB
UNSPSC: 39122331
UPC: 04013614497377
$125.10 / 10Each
- ABB, 1SVR405611R7100, Miniature Interface Relay, General Purpose Pluggable, Series: CR, 5 mA, 0.3 W Power, 50/60 Hz Frequency, 110 VAC Coil, 2CO-SPDT Contact Form, 12 A at 250 VAC Contact, Socket Mounting, IP40 Enclosure, -40 to 55 deg C, 35.6 mm H x 21.2 mm W x 27.5 mm D Dimensions
1SVR405611R7100 Application
For CR type plug-in relays1SVR405611R7100 Item Features
- Standard miniature relays with mechanical status indication
- Suited for logical and standard sockets
- Pluggable function modules - reverse polarity protection/free wheeling diode, LED indication, RC elements, overvoltage protection, time modules
- The relay has an integrated blue test button for manual actuation and locking of the output contacts
- Cadmium free contact
1SVR405611R7100 Standards
RoHS Compliant|CE/CSA/GOST Certified|UL Listed|CE MarkedSKU #2223534Part Number #1SVR405611R7100UNSPSC39122331UPC04013614497377
