ABB 1SVR405618R3100 Pluggable Interface Relay
Image Disclaimers Message
ABB 1SVR405618R3100 Pluggable Interface Relay
ABB 1SVR405618R3100 Pluggable Interface Relay
Part #:1SVR405618R3100
SKU #: 2282314
Key Features
Part #:1SVR405618R3100
SKU #: 2282314
Brand: ABB
Coil Voltage: 230, 230 VAC
Contact Form: 4CO-SPDT
Contact Rating: 6 A at 250 V
Dimensions: 21.2 mm W x 27.5 mm D x 35.6 mm H
Display Type: LED
- Standard miniature relays with mechanical status indication
- Integrated test button for manual actuation and locking of output contacts (DC coil = blue, AC coil = orange) that can be removed if necessary
- Cadmium-free contact material
- Suited for logical and standard sockets
- 27 in W on socket
ABB 1SVR405618R3100 Pluggable Interface Relay
ABB Pluggable Interface Relay, Series: CR-M, 50/60 Hz, 230 VAC Coil, 4CO-SPDT, 6 A at 250 V Contact, LED, IP40 Enclosure, -40 to 55 deg C, 21.2 mm W x 27.5 mm D x 35.6 mm H
Additional Description: ABB -1SVR405618R3100 (N) CR-M230AC4LG PLUGGABLE RELAY NON-CANCELABLE, NON-RETURNABLE
Catalog Description: The CR-M230AC4LG pluggable interface relay is from the CR-M (miniature) relay range. This relay operates with a 230 V AC rated control supply voltage and has a 4 c/o (SPDT) gold-plated output with contacts rated at 250 V / 6 A. The relay has an integrated orange test button for manual actuation and locking of the output contacts and an integrated LED. Standard sockets, logic sockets, pluggable function modules, holder and marker are available as accessories
