1SVR405621R1100
ABB 1SVR405621R1100 Universal Interface Relay
Part Number # 1SVR405621R1100
SKU # 2412785
ABB 1SVR405621R1100 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | 1SVR405621R1100 |
| SKU #: | 2412785 |
| Amperage Rating: | 5 mA |
| Coil Voltage: | 24 VDC |
| Contact Form: | 2CO 2 Form C DPDT, 2CO/DPDT |
| Contact Rating: | 10 A at 250 VAC |
| Dimensions: | 54.4 mm H x 35 mm W x 35 mm D |
| Enclosure Type: | IP40 |
| Series: | CR |
| Temperature Rating (Degrees F): | -40 to 70 deg C |
| Type: | General Purpose Pluggable |
| Country of origin: | LT |
| Mounting type: | Socket |
| Manufacturer Name: | ABB |
| UNSPSC: | 39122331 |
| UPC: | 04013614498381 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ABB 1SVR405621R1100 Universal Interface Relay
Brand: ABB
Part Number: 1SVR405621R1100
ABB Universal Interface Relay, General Purpose Pluggable, Series: CR, 5 mA, 0.3 W Power, 24 VDC Coil, 2CO-DPDT Contact Form, 10 A at 250 VAC Contact, Socket Mounting, IP40 Enclosure, -40 to 70 deg C, 54.4 mm H x 35 mm W x 35 mm D Dimensions
Additional Description: ABB -1SVR405621R1100 (N) CR-U024DC2L PLUGGABLE RELAY NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Plugin control relay with 24 VDC rated control supply voltage, DPDT (2 c/o) with LED indicator and 250 V, 10 A contact rating
1SVR405621R1100 Application
For DPDT plug-in control relays1SVR405621R1100 Item Features
- Standard miniature relays with mechanical status indication
- The relay has an integrated blue test button for manual actuation and locking of the output contacts
- Suited for logical and standard sockets
- Cadmium free contact
- Pluggable function modules - reverse polarity protection/free wheeling diode, LED indication, RC elements, overvoltage protection, time modules
1SVR405621R1100 Standards
RoHS Compliant|UL Listed|CE Certified|CSA Certified|RoHS Compliant|CE/CSA/GOST Certified|UL ListedSKU #2412785Part Number #1SVR405621R1100UNSPSC39122331UPC04013614498381
