Part Number # 1SVR405621R7100
SKU # 2369570
Image Disclaimers Message
1SVR405621R7100
ABB 1SVR405621R7100 Interface Relay
Part Number # 1SVR405621R7100
SKU # 2369570
ABB 1SVR405621R7100 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | 1SVR405621R7100 |
| SKU #: | 2369570 |
| Coil Voltage: | 110, 110 VAC |
| Contact Form: | 2CO 2 Form C SPDT, 2CO-SPDT, 2CO/SPDT |
| Contact Rating: | 250 V, 10 A |
| Dimensions: | 35 mm L x 35 mm W x 54.4 mm H |
| Display Type: | LED |
| Frequency Rating: | 50/60, 50/60 Hz |
| Series: | CR-U |
| Type: | Pluggable Universal |
| Country of origin: | LT |
| Manufacturer Name: | ABB |
| UNSPSC: | 39122331 |
| UPC: | 04013614498503 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ABB 1SVR405621R7100 Interface Relay
Brand: ABB
Part Number: 1SVR405621R7100
ABB Interface Relay, Pluggable Universal, Series: CR-U, 2.5/2.8 VA Power, 50/60 Hz Frequency, 110 VAC Coil, 2CO-SPDT Contact Form, 250 V, 10 A Contact, LED Display, 35 mm L x 35 mm W x 54.4 mm H Dimensions
Additional Description: ABB -1SVR405621R7100 CR-U110AC2L PLUGGABLE RELAY
Catalog Description: The CR-U110AC2L pluggable interface relay is from the CR-U (universal) relay range. This relay operates with a 110 V AC rated control supply voltage and has 2 c/o (SPDT) output contacts rated at 250 V / 10 A. The relay has an integrated orange test button for manual actuation and locking of the output contacts and an integrated LED. Standard sockets, logic sockets, pluggable function modules, holder and marker are available as accessories.
1SVR405621R7100 Application
For applications where low current control voltage is used to switch higher current or voltage loads1SVR405621R7100 Item Features
- The relay has an integrated orange test button for manual actuation and locking of the output contacts
1SVR405621R7100 Standards
UL Listed|cUL/UL Recognized|CSA Certified|EAC ApprovedSKU #2369570Part Number #1SVR405621R7100UNSPSC39122331UPC04013614498503
