ABB AF265-30-11-34 Line Contactor

2329025 MFG #: AF265-30-11-34
$812.85 / EA
Usually Ships within 5-8 Days
  • Coil Power Rating: 75 hp, 100 hp, 200 hp, 250 hp
  • Coil Voltage: 250 to 500
  • Contact Configuration: 3NO
  • Contact Rating: 265 A at 440 V
  • Dimensions: 140 mm W x 195.5 mm D x 225 mm H
  • Enclosure Type: IP20/IP00
  • Maximum Load Current: 350
  • Number of Auxiliary Contacts: 1NO-1NC
  • Number of Poles: 3
  • Operating Cycles: 5000000
  • Operating Temperature: -40 to 70
  • Series: AF Series
  • Size: AF265
  • Terminal Type: Box Lug
  • Type: Non-Reversing
  • Wattage: 160/75/132/200

ABB AF265-30-11-34 Line Contactor

ABB Line Contactor, Non-Reversing, Series: AF Series, 250 to 500 VAC/VDC Coil, 350 A Maximum Load Current, 75 hp, 100 hp, 200 hp, 250 hp Coil, 3 Pole, 160/75/132/200 kW Wattage, 3NO Contact Configuration, 1NO-1NC Auxiliary Contacts, 265 A at 440 V Contact, AF265 Size, Box Lug Terminal, IP20/IP00 Enclosure, 5000000 Cycles Operating Cycles, -40 to 70 deg C Operating, 140 mm W x 195.5 mm D x 225 mm H Dimensions

Additional Description: ABB -AF265-30-11-34 CONTACTOR 3 POLE 250HP 600VAC

Catalog Description: A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 1000 V. Controlled with PLC and with wide control voltage range 250-500 V, AC/DC

  • Specifications
  • Control circuit - AC or DC operated with electronic coil interface accepting a wide control voltage range (e.g. 100 to 250 VAC and VDC), only 4 control voltage ranges covering 24 to 500 V 50/60 Hz and 20 to 500 VDC
  • 160 kW at 1000 V, 75 kW at 220/230/240 V, 132 kW at 380/400 V, 132 kW at 415 V, 160 kW at 440 V, 200 kW at 500 V, 200 kW at 690 V
  • Can manage large control voltage variations
  • Reduced panel energy consumption
  • Very distinct closing and opening
  • Can withstand short voltage dips and voltage sags
  • Built-in surge suppression
  • Add-on auxiliary contact blocks for side mounting and a wide range of accessories
  • 113 A at 1000 V, 265 A at 220/230/240 V, 265 A at 380/400 V, 265 A at 415 V, 265 A at 440 V, 250 A at 500 V, 250 A at 690 V rated operational current AC-3
  • 75 hp at 200 VAC 3 ph, 75 hp at 208 VAC 3 ph, 100 hp at 220 to 240 VAC 3 ph, 200 hp at 440 to 480 VAC 3 ph, 250 hp at 550 to 600 VAC 3 ph
