Part Number # AF26ZB-22-00RT-23
SKU # 2441335
Image Disclaimers Message
Brand: ABB
AF26ZB-22-00RT-23
ABB AF26ZB-22-00RT-23
Part Number # AF26ZB-22-00RT-23
SKU # 2441335
$226.64 / Each
Typical price:$420.87 / Each
ABB AF26ZB-22-00RT-23 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | AF26ZB-22-00RT-23 |
| SKU #: | 2441335 |
| Coil Power Rating: | 5.5/9/11 kW |
| Coil Voltage: | 100 to 250 V AC/DC, 100 to 250 VAC/VDC |
| Contact Configuration: | 2NO-2NC |
| Dimensions: | 86 mm H x 45 mm W x 101 mm D |
| Enclosure Type: | IP20 |
| Frequency Rating: | 50/60 Hz |
| Number of Poles: | 4 |
| Operating Cycles: | 10000000 Cycles |
| Operating Temperature: | -40 to 70 deg C |
| Terminal Type: | Screw |
| Type: | DC Operated Low Coil Consumption |
| Connection type: | Double Connector |
| Country of origin: | FR |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121529 |
| UPC: | 03471523129931 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$226.64 / Each
Typical price:$420.87 / Each
Quantity:
- ABB IEC Contactor, DC Operated Low Coil Consumption, 100 to 250 V AC/DC Coil, 45 A Maximum Load Current, 5.5/9/11 kW Coil, 4 Pole, 50/60 Hz Frequency, 2NO-2NC Contact Configuration, Double Connector Connection, Screw Terminal, IP20 Enclosure, 10000000 Cycles Operating Cycles, -40 to 70 deg C Operating, 86 mm H x 45 mm W x 101 mm D Dimensions
AF26ZB-22-00RT-23 Application
For controlling non-inductive or slightly inductive loads and generally for controlling power circuits up to690VAC and440VDCAF26ZB-22-00RT-23 Item Features
- Designed in accordance to the applicable parts of IEC60077and EN50155standard
- Shocks and vibration withstand conforming to IEC61373(category1, class B)
- Fire and smoke safety compliance to European standard EN 45545 (HL2, HL3 hazard levels)
- Electronic coil interface accepting a wide DC control voltage range (0.85 Ucminimum to 1.1Ucmaximum according to IEC60947-4-1) including several Uc control voltages (0.7 to 1.25Uc according to IEC60077) used for battery supply
- Built-in surge suppression
- Side by side mounting without restriction from -40to 70 deg C
- 5.5 kW at 220 to 230 to 240 V, 11 kW at 380 to 400/415/440/500 V, 9 kW at 690 V
- 45 A at 600 V UL/CSA, 1-phase 690 V IEC
AF26ZB-22-00RT-23 Standards
IEC 60947-1|IEC 60947-4-1|EN 60947-1|EN 60947-4-1|UL 508|CSA C22.2 File No. 14|IEC 60077|EN 50155|IEC 61373|EN 45545SKU #2441335Part Number #AF26ZB-22-00RT-23UNSPSC39121529UPC03471523129931
