ABB E16DU18.9 Electronic Overload Relay

2177938 MFG #: E16DU18.9
$96.15 / EA
Usually Ships within 5-8 Days
  • Amperage Rating: 18.9, 5.7 to 18.9
  • Coil Voltage: 600
  • Contact Form: 1NO-1NC
  • Contact Rating: 690 VAC, 18.9 A
  • Dimensions: 57 mm L x 44.4 mm W x 74.6 mm H, 74.6 mm H x 44.4 mm W x 57 mm D
  • Enclosure Type: IP20
  • Frequency Rating: 50/60
  • Number of Poles: 3
  • Series: E16
  • Temperature Rating (Degrees F): -13 to 158, -25 to 70
  • Type: Class 10/20/30, Electronic

ABB E16DU18.9 Electronic Overload Relay

ABB Electronic Overload Relay, Class 10/20/30, 5.7 to 18.9 A, 50/60 Hz Frequency, 1NC-1NO Contact Form, 690 VAC, 18.9 A Contact, 3 Pole, IP20 Enclosure, -25 to 70 deg C, 57 mm L x 44.4 mm W x 74.6 mm H Dimensions

Additional Description: ABB -E16DU18.9 EOL,CL 10,20,30,5.7-18.9A NON-CANCELABLE, NON-RETURNABLE

Catalog Description: The E16DU-18.9 is an self-supplied electronic overload relay, which means no extra external supply is needed. It offers reliable and fast protection for motors in the event of overload or phase failure. Easy to use like a thermal overload relay and compatible with standard motor applications, the electronic overload relay is convincing, above all, due to its wide setting range, high accuracy, high operational temperature range and the possibility to select a trip class (10E, 20E, 30E). Further features are the temperature compensation, trip contact (NC), signal contact (NO), automatic- or manual reset selectable, trip-free mechanism, STOP- and Test function and a trip indication. The overload relays are connected directly to the contactors. Single mounting kits are available as accessory.

  • Specifications
  • 5.7 to 18.9 A setting range
  • It offers reliable and fast protection for motors in the event of overload or phase failure
