LS35P10B11
ABB LS35P10B11 Limit Switch
Part Number # LS35P10B11
SKU # 2205034
$430.70 / 10Each
Typical price:$431.20 / Each
ABB LS35P10B11 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | LS35P10B11 |
| SKU #: | 2205034 |
| Action: | Snap, Zb Snap |
| Actuator: | Plain Plunger |
| Amperage Rating: | 0.27/0.6/1.8/2.8/3/3.1/5.5/10 A |
| Connection type: | 1-1/2 in NPT Cable, 1/2 in NPT |
| Contact Configuration: | 1NC-1NO, 1NO-1NC |
| Contact Rating: | 10 A at 24 V |
| Country of origin: | IT |
| Enclosure Type: | IP65, NEMA 4/IP65 |
| Environmental Conditions: | -30 to 80 deg C Storage Temperature |
| Frequency Rating: | 50/60 Hz |
| Material: | Fiberglass Reinforced, Plastic |
| Mounting type: | Threaded |
| Operating Cycles: | 3600 Cycles/hr |
| Operating Temperature: | -25 to 70, -25 to 70 deg C |
| Series: | LS Series |
| Size: | 30 mm W, 30 mm W x 30 mm D x 73 mm H |
| Type: | Standard |
| Manufacturer Name: | ABB |
| UNSPSC: | 39122213 |
| UPC: | 03471522610010 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$430.70 / 10Each
Typical price:$431.20 / Each
Quantity:
- ABB, LS35P10B11, Limit Switch, Standard, Series: LS Series, 24/130/230/240/400 VAC, 24/110/250 VDC, 0.27/0.6/1.8/2.8/3/3.1/5.5/10 A, 50/60 Hz Frequency, 1NO-1NC Contact Configuration, 10 A at 24 V Contact, 25 mOhm Closed Contact Resistance, Snap Action, Plain Plunger Actuator, 1/2 in NPT Connection, Class II Insulation, NEMA 4/IP65 Enclosure, Threaded Mounting, 30 mm W Size, 3600 Cycles/hr Operating Cycles, -25 to 70 deg C Operating, Plastic, Environmental Conditions: -30 to 80 deg C Storage Temperature
LS35P10B11 Application
For presence/absence, positioning and travel limit, objects passing/counting mechanical applicationsLS35P10B11 Item Features
- 10 A at 24 VAC, 5.5 A at 130 VAC, 3.1 A at 230 VAC, 3 A at 240 VAC, 1.8 A at 400 VAC at AC-15, 2.8 A at 24 VDC, 0.6 A at 110 VDC, 0.27 A at 250 VDC at DC-13
- (2) Mounting holes at the top
- 0.55 A at 125 V, 6 A at 24 V, 0.4 A at 250 V, 0.6 A at 110 V rated operational current DC-13
- Immune to electromagnetic disturbances
- Able to switch strong currents (10 A conventional thermal current)
- Precise operating points (consistency)
- Electrically separated contacts
- Visible operation
LS35P10B11 Standards
RoHs, CSA, cUL, CE, GOSTSKU #2205034Part Number #LS35P10B11UNSPSC39122213UPC03471522610010
