Part Number # LS35P11B11
SKU # 833744
Image Disclaimers Message
Brand: ABB
LS35P11B11
ABB LS35P11B11 LS Series Limit Switch, 600/690 VAC, Plunger Actuator, 1NC-1NO Contact
Part Number # LS35P11B11
SKU # 833744
$430.70 / 10Each
Typical price:$431.20 / Each
ABB LS35P11B11 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | LS35P11B11 |
| SKU #: | 833744 |
| Action: | Zb Snap |
| Actuator: | Plunger |
| Amperage Rating: | 2.8/10 A |
| Connection type: | 1/2 in NPT |
| Contact Configuration: | 1NC-1NO, 1NO-1NC |
| Country of origin: | IT |
| Enclosure Type: | NEMA 4/IP65 |
| Environmental Conditions: | -30 to 80 deg C Storage Temperature |
| Frequency Rating: | 50/60 Hz |
| Material: | Plastic |
| Mounting type: | Screw |
| Operating Cycles: | 3600 Cycles |
| Operating Temperature: | -25 to 70 deg C |
| Series: | LS Series |
| Size: | 30 mm |
| Manufacturer Name: | ABB |
| UNSPSC: | 39122213 |
| UPC: | 03471522610072 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$430.70 / 10Each
Typical price:$431.20 / Each
Quantity:
- ABB, LS35P11B11, Limit Switch, Series: LS Series, 600/690 V AC, 2.8/10 A, 50/60 Hz Frequency, 1NO-1NC Contact Configuration, 25 mOhm Closed Contact Resistance, Zb Snap Action, Plunger Actuator, 1/2 in NPT Connection, Class II/Double Insulation, NEMA 4/IP65 Enclosure, Screw Mounting, 30 mm Size, 3600 Cycles Operating Cycles, -25 to 70 deg C Operating, Plastic, Environmental Conditions: -30 to 80 deg C Storage Temperature
LS35P11B11 Item Features
- 130 VAC at 5.5 A, 230 VAC at 3.1 A, 240 VAC at 3 A, 24 VAC at 10 A, 400 VAC at 1.8 A rated operational current
- 110 VDC at 0.6/66 A, 24 VDC at 2.8/67.2 A, 250 VDC at 0.27/67.5 A
LS35P11B11 Standards
RoHs, CSA, cUL, CE, GOSTSKU #833744Part Number #LS35P11B11UNSPSC39122213UPC03471522610072
