Part Number # LS45M42B11
SKU # 2398227
Image Disclaimers Message
Brand: ABB
LS45M42B11
ABB LS45M42B11 Limit Switch
Part Number # LS45M42B11
SKU # 2398227
$111.63 / Each
Typical price:$111.76 / Each
ABB LS45M42B11 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | LS45M42B11 |
| SKU #: | 2398227 |
| Action: | Zb Snap |
| Actuator: | Stainless Steel Roller Lever |
| Amperage Rating: | 5.5/3.1/3/10/1.8 A |
| Connection type: | 1/2 in NPT |
| Contact Configuration: | 1NC-1NO, 1NO-1NC |
| Country of origin: | IT |
| Enclosure Type: | NEMA 4X/IP66 |
| Frequency Rating: | 50/60 Hz |
| Material: | Metal |
| Mounting type: | Threaded |
| Operating Cycles: | 3600 Cycles |
| Operating Temperature: | -25 to 70 deg C |
| Series: | LS Series |
| Size: | 40 mm W |
| Manufacturer Name: | ABB |
| UNSPSC: | 39122213 |
| UPC: | 03471522613738 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$111.63 / Each
Typical price:$111.76 / Each
Quantity:
- ABB Limit Switch, Series: LS Series, 24/130/230/240/400 VAC, 5.5/3.1/3/10/1.8 A, 50/60 Hz Frequency, 1NO-1NC Contact Configuration, 25 mOhm Closed Contact Resistance, Zb Snap Action, Stainless Steel Roller Lever Actuator, 1/2 in NPT Connection, NEMA 4X/IP66 Enclosure, Threaded Mounting, 40 mm W Size, 3600 Cycles Operating Cycles, -25 to 70 deg C Operating, Metal
LS45M42B11 Item Features
- 1.5 m/sec maximum actuation speed
- 0.15 Nm minimum force/torque actuation
- 0.44 Nm minimum force/torque positive opening operation
LS45M42B11 Standards
UL ListedSKU #2398227Part Number #LS45M42B11UNSPSC39122213UPC03471522613738
