ABB MO132-2.5 Manual Motor Starter Magnetic Only

2359416 MFG #: MO132-2.5
$99.25 / EA
Usually Ships within 5-8 Days
  • Action: On/Off/Trip
  • Amperage Rating: 2.5
  • Control Type: Rotary Handle
  • Dimensions: 45 mm W x 86.75 mm D x 90 mm H
  • Enclosure Type: IP20/IP109
  • Frequency Rating: 50/60
  • Full Load Current: 2.5
  • Load Capacity: 100
  • Motor Power: 1.5
  • Number of Poles: 3
  • Operating Cycles: 50000/100000
  • Operating Temperature: -25 to 60
  • Phase: 3
  • Series: MO132
  • Setting: 1.6 to 2.5
  • Voltage Rating: 600
  • Wattage: 0.75
  • Connection type: Screw

ABB MO132-2.5 Manual Motor Starter Magnetic Only

ABB Manual Motor Starter Magnetic Only, Series: MO132, 600 VAC, 2.5 A, 50/60 Hz Frequency, 0.75 kW Wattage, 1.5 hp Motor, 3 Pole, Setting: 1.6 to 2.5 A, 100 kA Load, 3 ph, Screw Connection, On-Off/Trip Action, 2.5 A Full Load, Rotary Handle Control, IP20/IP109 Enclosure, 50000/100000 Cycles Operating Cycles, -25 to 60 deg C Operating, 45 mm W x 86.75 mm D x 90 mm H Dimensions

Additional Description: ABB -MO132-2.5 3P MMP 1.6-2.5A RANGE, MAG ONLY NON-CANCELABLE, NON-RETURNABLE

Catalog Description: The MO132-16 manUAl motor starter mangnetic only is a compact 45 mm width devices with a rated operational current of ie = 16.0 a. this device is used to manUAlly switch on and off loads/motors and to protect them reliably and without the need for a fuse from short-circuits. The manUAl motor starter offers a rated service short-circuit breaking capacity ics = 50 ka at 400 vac. a combination together with overload relays or motor controllers allows the protection of motors. further features are the build-in disconnect function, trip-free mechanism and a rotary handle with a clear switch position indication. The manUAl motor starter mangnetic only is suitable for three- and single-phase applications. The handle is lockable to protect against unauthorized changes. auxiliary contacts, signalling contacts, undervoltage releases, shunt trips, 3-phase bus bars, power in-feed blocks are available as accessory.

  • Specifications
  • Short-circuit protection
  • Disconnect function
  • Trip-free mechanism
  • 2.5 A at 200 VAC 3 ph, 2.5 A at 208 VAC 3 ph, 2.5 A at 220 to 240 VAC 3 ph, 2.5 A at 440 to 480 VAC 3 ph, 2.5 A at 550 to 600 VAC 3 ph
  • 0.5 hp at 200 VAC 3 ph, 0.5 hp at 208 VAC 3 ph, 0.5 hp 220 to 240 VAC 3 ph, 1 hp 440 to 480 VAC 3 ph, 1.5 hp 550 to 600 VAC 3 ph
