MO132-20
ABB MO132-20 Magnetic Manual Motor Starter, ON/OFF/Trip Action, 3 Poles, IP20 Enclosure
Part Number # MO132-20
SKU # 2428420
$213.25 / Each
Typical price:$254.87 / Each
ABB MO132-20 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | MO132-20 |
| SKU #: | 2428420 |
| Action: | On/Off/Trip |
| Amperage Rating: | 20 A |
| Dimensions: | 1.77 in W |
| Enclosure Type: | IP20 |
| Frequency Rating: | 50/60 Hz |
| Full Load Current: | 14/15/15.2/17/19.2 A |
| Motor Power: | 3 hp, 5 hp, 10 hp, 15 hp |
| Number of Poles: | 3 |
| Operating Cycles: | 50000/100000 Cycles |
| Operating Temperature: | -25 to 60 deg C |
| Phase: | 1/3 |
| Series: | MO132 |
| Setting: | 16 to 20 A |
| Type: | Magnetic |
| Wattage: | 9 kW |
| Connection type: | Screw |
| Country of origin: | DE |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121521 |
| UPC: | 04013614400285 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$213.25 / Each
Typical price:$254.87 / Each
Quantity:
- ABB, MO132-20, Manual Motor Starter, Magnetic, Series: MO132, 690 VAC, 250 VDC, 20 A, 50/60 Hz Frequency, 9 kW Wattage, 3 hp, 5 hp, 10 hp, 15 hp Motor, 3 Pole, Setting: 16 to 20 A, 1/3 ph, Screw Connection, ON/OFF/Trip Action, 14/15/15.2/17/19.2 A Full Load, IP20 Enclosure, 50000/100000 Cycles Operating Cycles, -25 to 60 deg C Operating, 1.77 in W Dimensions
MO132-20 Item Features
- Disconnect function
- 50000 mechanical, 100000 electrical cycles
- 17 A at 220 to 240 VAC 1 phase, 14 A at 440 to 480 VAC 1 phase, 19.2 A at 110 to 120 VAC 3 phase, 15.2 A at 220 to 240 VAC 3 phase, 14 A at 440 to 480 VAC 3 phase, 17 A at 500 to 600 VAC 3 phase full load current rating
- Trip-free mechanism
- Suitable for three and single-phase applications
- Clear switch position indication On-Off/trip
- Short-circuit protection
- Lockable handle
MO132-20 Standards
RoHs, CSA, cUL, CE, GOSTSKU #2428420Part Number #MO132-20UNSPSC39121521UPC04013614400285
