Part Number # TNL22ERT-51
SKU # 2416090
Image Disclaimers Message
TNL22ERT-51
ABB TNL22ERT-51 Contactor Relay
Part Number # TNL22ERT-51
SKU # 2416090
$114.76 / Each
Typical price:$195.25 / Each
ABB TNL22ERT-51 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | TNL22ERT-51 |
| SKU #: | 2416090 |
| Amperage Rating: | 10 A |
| Coil Voltage: | 17/32 V DC, 17/32 VDC |
| Contact Form: | 2NO-2NC, 2NO-2NC 2 Form A/2 Form B |
| Dimensions: | 97 mm L x 44 mm W x 78 mm H |
| Enclosure Type: | IP20 |
| Number of Poles: | 4 |
| Series: | TNL |
| Temperature Rating (Degrees F): | -60 to 80 deg C |
| Terminal Type: | Screw |
| Country of origin: | CZ |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121529 |
| UPC: | 03471522363916 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$114.76 / Each
Typical price:$195.25 / Each
Quantity:
- ABB Contactor Relay, Series: TNL, 10 A, 17/32 V DC Coil, 2NO-2NC 2 Form A/2 Form B Contact Form, 4 Poles, Screw Terminal, IP20 Enclosure, -60 to 80 deg C, 97 mm L x 44 mm W x 78 mm H Dimensions
TNL22ERT-51 Application
For switching auxiliary and control circuitsTNL22ERT-51 Item Features
- DC operated with solid core magnet circuit
- The polarity on the coil terminals (A1+ and A2-) must be respected
TNL22ERT-51 Standards
IEC/EN 60529|IEC 60947-1|CE Certified|EAC ApprovedSKU #2416090Part Number #TNL22ERT-51UNSPSC39121529UPC03471522363916
