Advance Lighting IMH150HLFM e-Vision Metal Halide Ballast
Part Number # IMH150HLFM
SKU # 2281952

IMH150HLFM
Advance Lighting IMH150HLFM e-Vision Metal Halide Ballast
Part Number # IMH150HLFM
SKU # 2281952
$1379.04 / 6Each
Typical price:$1930.68 / Each
Advance Lighting IMH150HLFM Key Features
| Brand: | Advance Lighting |
|---|---|
| Part Number # : | IMH150HLFM |
| SKU #: | 2281952 |
| Dimensions: | 6.4 in L x 3.7 in W x 1.5 in H |
| Enclosure Type: | NEMA 4C |
| Total Harmonic Distortion: | 15 % |
| Type: | Electronic HID Fixed Output |
| Wattage: | 165 W |
| Temperature range: | 85 deg C |
| UNSPSC: | 39101907 |
| UPC: | 00781087055595 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Prices are in USD. Orders shipped to Canada may be subject to duties, taxes and brokerage fees, collected by the carrier on delivery.
$1379.04 / 6Each
Typical price:$1930.68 / Each
Quantity:
- Advance e-Vision Metal Halide Ballast, Electronic HID Fixed Output, 150 W Lamp, 165 W Wattage, 120 to 277 V AC, 1.4 A, 50/60 Hz Frequency, Pulse Start, -20 deg F Minimum Starting, Total Harmonic Distortion: 15 %, Power Factor: 0.9, 1 Lamp, Ballast Factor: 1, ANSI M102/M142 Ballast Grade, NEMA 4C Enclosure, 85 deg C, Surface Mounting, Metal, 6.4 in L x 3.7 in W x 1.5 in H Dimensions
IMH150HLFM Specifications
- Low frequency electronic HID ballasts such as the Philips Advance e-Vision® line constantly measure and adjust the wattage, optimizing delivery of the ceramic lamps superior color properties
- This makes ceramic metal halide operated by e-Vision® ballasts the premier choice for many applications previously illuminated by either tungsten halogen or incandescent sources, such as retail lighting
- Leads (side exit) with mounting feet
IMH150HLFM Item Features
- Low frequency electronic HID ballasts such as the Philips Advance e-Vision line constantly measure and adjust the wattage, optimizing delivery of the ceramic lamps superior color properties
- This makes ceramic metal halide operated by e-Vision ballasts the premier choice for many applications previously illuminated by either tungsten halogen or incandescent sources, such as retail lighting
- Leads (side exit) with mounting feet
IMH150HLFM Standards
CSA Certified|UL ListedSKU #2281952Part Number #IMH150HLFMUNSPSC39101907UPC00781087055595
Image provided may only be a representation of final product and may include optional equipment
