Appleton 4Q400L Conduit Connector
Brand: Appleton
Part Number: 4Q400L
O-Z/Gedney Ground-Tite Conduit Connector, Concretetight Liquid Tight Oiltight Positive Grounding Raintight, Series: 4Q-L, 4 in, Cable Openings: 1 to 4/0 AWG, Straight, For Use With: Liquid Tight Flexible Metallic Conduit, Malleable Iron, Zinc Electroplated, 3-1/2 in H x 6-1/2 in W
Additional Description: APLE-4Q400L 4 IN STR CONN LFMC W/LUG
Catalog Description: OZ-Gedney Ground-Tite Type 4Q-L Grounding Liquid Tight Straight Connector With Lug, Size: 4 IN, Connection: Tapered MNPT Hub, Conductor Range: 1 - 4/0 AWG, Malleable Iron Body And Nut, Steel Ferrule, Finish: Zinc Electroplated, NEMA Rating: NEMA 4
4Q400L Application
Ground and Seal Liquid tight Flexible Metal Conduit to Boxes and Enclosures4Q400L Includes
Locknut and KO Sealing Ring4Q400L Item Features
- Tapered threaded male NPT hub
- Compact, slim diameter with small turning radius
- Intrinsically safe
- Bonding wedge locknuts are recommended in hazardous locations
- Long ferrule prevents pullout and tight bend conduit "pop-out"
- Inspection windows in ferrule to ensure full conduit engagement
- Grounding lug is cast as an integral part of malleable iron gland nut
- Capable of withstanding high ground fault
4Q400L Standards
ARRA Compliant|RoHS Compliant|UL File No. E-24264|CSA 009795|UL 467|CSA C22.2 File No. 41|Federal Specification W-F-406E, Class I, Div 2 Per NEC 501.4(B), Class I, Zone 2 Per NEC 505.15(C)(2), Class II, Div 1 Per NEC 502.4(A)(1)(e), Class II, Div 2 Per NEC 502.4(B)(2), Class III, Div 1 Per NEC 503.3(A)(2), Class III, Div 2 Per NEC 503.3(B)|NEC 504.204Q400L Warranty
LimitedSKU #2211517Part Number #4Q400LUNSPSC39121420UPC00783126618068
