Appleton EDSK1MSW Motor Starter
Part Number # EDSK1MSW
SKU # 2358236
Appleton EDSK1MSW Key Features
| Brand: | Appleton |
|---|---|
| Part Number # : | EDSK1MSW |
| SKU #: | 2358236 |
| Dimensions: | 7.03 in H x 3.72 in W x 5.31 in D |
| Enclosure Type: | NEMA 3/7C/7D/9E/9F/9G, NEMA 3/7CD/9EFG |
| Motor Power: | 1 hp, 1/4 hp |
| Number of Poles: | 1 |
| Series: | EDSK |
| Type: | Factory Sealed |
| Country of origin: | MX |
| Material: | Malleable Iron |
| Manufacturer Name: | Emerson Electric |
| UNSPSC: | 39121521 |
| UPC: | 00781381801959 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Appleton EDSK1MSW Motor Starter
Brand: Appleton
Part Number: EDSK1MSW
Appleton Contender Motor Starter, Factory Sealed, Series: EDSK, 115/230 VAC, 1 hp, 1/4 hp Motor, 1 Pole, NEMA 3/7C/7D/9E/9F/9G Enclosure, Starting Modes: Manual, Malleable Iron, 7.03 in H x 3.72 in W x 5.31 in D Dimensions
Additional Description: APLE-EDSK1MSW (N) EFD MANUAL MOTOR SRARTER NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Contender Manual Starter Cover, Number Of Poles: 1, Enclosure: NEMA 3, Hub Size: 1/2, 3/4, 1 IN, Standard: Class I, Division 1 And 2, Groups C, D, Class II, Division 1 And 2, Groups E, F, G, Class III, For 1-Gang Or 2-Gang Dead-End Or Fe
EDSK1MSW Application
For installing a variety of electrical wiring devicesEDSK1MSW Includes
Cover, Chamber and DeviceEDSK1MSW Item Features
- Easily readable operator handle with provisions for padlocking in the on/off position
- Interchangeable heater units
- Cast in hubs
EDSK1MSW Standards
cULus, E76550, E81751|UL 508, 698, 1203 Listed|CSA C22.2 No. 14-M, 25, 30 Certified|NEC Certified|CEC Class I, Division 1, 2, Groups C, D|Class II, Division 1, 2, Groups E, F, G|Class III CertifiedSKU #2358236Part Number #EDSK1MSWUNSPSC39121521UPC00781381801959
Image provided may only be a representation of final product and may include optional equipment
