EYD36
Appleton EYD36
Part Number # EYD36
SKU # 2466459
$73.49 / Each
Typical price:$129.92 / Each
Appleton EYD36 Key Features
| Brand: | Appleton |
|---|---|
| Part Number # : | EYD36 |
| SKU #: | 2466459 |
| Dimensions: | 4.31 in L x 2.19 in W |
| Series: | EYD |
| Suitable For Use With: | IMC/Threaded Rigid Metallic Conduit |
| Type: | Dust-Ignitionproof Explosionproof Raintight |
| Material: | Grayloy-Iron |
| UNSPSC: | 39121311 |
| UPC: | 00781381620895 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$73.49 / Each
Typical price:$129.92 / Each
Quantity:
- Appleton UNILETS Conduit Sealing Fitting, Dust-Ignitionproof Explosionproof Raintight, Series: EYD, 1 in, For Use With: IMC/Threaded Rigid Metallic Conduit, Grayloy-Iron, Gray, Triple Coated, 4.31 in L x 2.19 in W
EYD36 Application
For prevent passage of gases, vapors or flames from one portion of conduit system to anotherEYD36 Item Features
- Smooth, rounded integral bushing in each hub to protect conductor insulation
- Accurately tapped, tapered NPT threads for tight, rigid joints and ground continuity
- Removable nipple in male sealing fitting may be used interchangeably in top or bottom hub
- Restrict any explosion to the sealed off enclosure
- Required in Class I, Division 1 and 2 locations within 18 in of enclosures containing apparatus that may cause arcs, sparks or high temperatures
- Required in Class I, Division 1 and 2 locations where 2 in or larger conduit enters enclosure, fitting housing terminals, splices or taps
- Required in Class I, Division 1 and 2 locations at the boundary where conduit leaves classified location
- Required in Class I, Division 1 and 2 locations where two or more enclosures are connected by 36 in or less conduit, seal must be located within 18 in of either enclosure
- Required where cables which exceed rate of gas or vapor transmission permitted for seals are used in Class I, Division 2 locations
- Tapered MNPT X tapered FNPT connection
- 25% fill vertical conduit drain sealing fittings
- Chromate/epoxy powder coated/zinc electroplated finish
EYD36 Standards
UL 886|UL 1203|UL File No. E10444|CSA C22.2 No. 30|CSA 065181|Class I, Div 1 and 2, Groups C, D|Class II, Div 1 and 2, Groups E, F, G|Class IIISKU #2466459Part Number #EYD36UNSPSC39121311UPC00781381620895
Image provided may only be a representation of final product and may include optional equipment
